B.3.6 Long Input Registers (4 byte unsigned registers, transmitted upper word / upper
byte first)
B.3.7 Floating Point (FP) Inputs (4 byte FP, transmitted upper word / upper byte first)
Revised Aug-2015
ControlWave I/O Expansion Rack Instruction Manual
Range: 2101-2260 (20 per board)
Example: To read the HSC timestamp register on board 7, find HSC
timestamp register in the first row of the table, below, then move down
that column until you reach the board 7 row to determine the HSC
timestamp register for that board, in this case (2233). So your Modbus
command should request register 2233.
HSC Counts Registers
I/O Slot
1 (2101-2120)
2 (2121-2140)
3 (2141-2160)
4 (2161-2180)
5 (2181-2200)
6 (2201-2220)
7 (2221-2240)
8 (2241-2260)
9 (2261-2280)
10 (2281-2300)
11 (2301-2320)
12 (2321-2340)
13 (2341-2360)
14 (2361-2380)
Range: 3101-3260 (20 per board)
Example: To read the eleventh FP input on board 7, go to the Board 7
column of the table, below, to determine the range of FP inputs for that
board, in this case 3221-3240. The eleventh FP input in that range
would be 3231, so your Modbus command should request FP input
3231.
I/O Slot
1 (3101-3120)
2 (3121-3140)
3 (3141-3160)
4 (3161-3180)
5 (3181-3200)
Open Modbus Interface
HSC Timestamp Register
(1-12)
2101-2112
2121-2132
2141-2152
2161-2172
2181-2192
2201-2212
2221-2232
2241-2252
2261-2272
2281-2292
2301-2312
2321-2332
2341-2352
2361-2372
(13)
2113
2133
2153
2173
2193
2213
2233
2253
2273
2293
2313
2333
2353
2373
FP Inputs
3101-3120
3121-3140
3141-3160
3161-3180
3181-3200
