Emerson ControlWave Instruction Manual page 136

ControlWave I/O Expansion Rack Instruction Manual
I/O Slot AI, AO Out of
Range Status
(1-16 or 1-8)
1 (101- 101-116 or
140) 101-108
2 (141- 141-156 or
180) 141-148
3 (181- 181-196 or
220) 181-188
4 (221- 221-236 or
260) 221-228
5 (261- 261-276 or
300) 261-268
6 (301- 301-316 or
340) 301-308
7 (341- 341-356 or
380) 341-348
8 (381- 381-396 or
420) 381-388
9 (421- 421-436 or
460) 421-428
10 (461- 461-476 or
500) 461-468
11 (501- 501-516 or
540) 501-508
12 (541- 541-556 or
580) 541-548
13 (581- 581-596 or
620) 581-588
14 (621- 621-636 or
660) 621-628
B.3.3 Input Registers (2 byte signed registers, transmitted upper byte first)
B-4
AI, AO HSC Input
Conversion State
Error Status Status (1-
(39) 12)
139 101-112
179 141-152
219 181-192
259 221-232
299 261-272
339 301-312
379 341-352
419 381-392
459 421-432
499 461-472
539 501-512
579 541-552
619 581-592
659 621-632
*
Note 1: First group must be set to 1 to have 2
board. Also, first group will always read as 0 - cleared as soon as
written.
Range: 101-260 (20 per board)
Example: To read AI register 8 on board 2, find AI value register in the
first row of the table, below, then move down that column until you
reach the board 2 row to determine the range of AI value register
numbers, for that board, in this case (121-136). The eighth coil in the
Open Modbus Interface
AO Fail to State HSC Reset
Status (9-32) Coils
Coils (1-12)
(9-32
(3 sets of 8) *See
Note 1
109-132
149-172
189-212
229-252
269- 292
309-332
349-372
389-412
429-452
469-492
509-532
549-572
589-612
629-652
nd
HSC Setup
Status
13-36 Coils
13-36 (2 sets
of 12)
101-112 113-136
141-152 153-176
181-192 193-216
221-232 233-256
261-272 273-296
301-312 313-336
341-352 353-376
381-392 393-416
421-432 433-456
461-472 473-496
501-512 513-536
541-552 553-576
581-592 593-616
621-632 633-656
two groups written to
Revised Aug-2015
