 AC adapter of camera*1
 ND filter (Used when the screen is highlighted)

1.2 Camera assembly

1.2.1 Open the tripod

As shown in figure 1-9，the height of the tripod is recommended to be directly
opposite the center of the screen or close to the height of the viewer.

1.2.2 Head Installation

Align the mounting hole at the bottom of tripod head with the positioning bolt of the
tripod, and turn the head clockwise tightly. As shown in figure 1-10.
Fig.1-7 AC Adapter
Fig.1-8 ND filter
Fig.1-9 The tripod opened
