simple screen。
Grid module： Check if there is a difference between the left 、right Pixel Pitch
and the upper 、 lower Pixel Pitch on the screen.
COB Module: Select the check cabinet if the screen to be calibrated is COB
display screen.
Four LEDS Arrangement ： Select the check cabinet if the screen to be
calibrated is Four LEDS Arrangement screen.
Pixel Pitch： The software will automatically display the value if the client is
connected to the server; the default value is 0, which is invalid, if the client is not
connected to the server. You can manually enter the actual value of the pixel
pitch.
arc-screen：Select the check cabinet if the screen is an arc-screen combined by
hard modules or cabinets. Folder width refers to the number of pixel columns
between the fold lines（as shown in Fig.3-6）.
Polygonal Screen ： Check when rectangular modules with the same row and
column are spliced into a screen with irregular boundary.
tance to ground ： The screen height above the ground, for automatic
recommendation for shooting distance.
