Summary of Contents for Colorlight Calibration Pro

  • Page 1 Calibration Pro User Manual Calibration Pro...

  • Page 2: Table Of Contents

    Calibration Pro User Manual Content 1. Introduction ..................... 1 1.1 Operational environment .............. 1 1.2 Camera assembly ................3 1.2.1 Open the tripod ..............3 1.2.2 Head Installation ..............3 1.2.3 Lens Installation ..............4 1.2.4 Camera Installation ............6 1.3 Installation and un-installation ............8 1.3.1 Installation ................8...
  • Page 3 Calibration Pro User Manual 3.4.1 Display with sender card ..........20 3.4.1.1 Sender Card Setting ..........21 3.5 Basic parameter setting ............... 23 3.6 Camera preparation ..............29 3.7 Camera adjustment ..............30 3.7.1 Auto adjustment ............... 30 3.7.2 Auto adjustment ............... 33 3.7.2.1 canon auto adjustment ..........
  • Page 4 Calibration Pro User Manual 3.9.2 Effect Evaluation ............. 47 3.10 Generate coefficient ..............49 3.10.1 Brightness extraction ............. 49 3.10.2 Generate coefficient ............50 3.10.3 Eliminate Camera Dust And Worms ......54 4. Single cabinet calibration ..............56 4.1 Create single cabinet calibration ..........56 4.2 Capture Gray Setting ..............57...
  • Page 5 Calibration Pro User Manual 5. Deseam Setting ..................68 5.1 Fuction Intrudction ..............68 5.2 Enable deseam ................68 5.3 Deseam factor ................68 5.4 Deseam only ................68 5.5 Eliminate difference ..............68 6. Effect Setting ..................70 6.1 Effect setting overview ............... 70 6.2 Turn on “Eliminate Differ”...
  • Page 6 Calibration Pro User Manual 8.4 Coef Adjust ..................81 9. Suggestion on calibration ..............82 10. FAQ ..................... 83...

  • Page 7: Introduction

    Calibration Pro User Manual 1. Introduction Calibration pro is a professional of LED display calibration software ,it was Colorlight, which integrates advanced algorithms ,such as AI intelligence and machine vision to achieve accurate and efficient calibration of the display. 1.1 Operational environment Components of calibration system ...
  • Page 8 Calibration Pro User Manual Fig.1-3 Lens CCM was re-equipped with Milivus 2/35 lens . Fig.1-4 Lens Canon was re-equipped with CCM6000 was  Head*1( Manfrotto-410, re-equipped with Manfrotto- Fig.1-5Head  Tripod*1( MT190GOC4TB -190GO is recommended) Fig.1-6 Tripod...

  • Page 9: Camera Assembly

    Calibration Pro User Manual  AC adapter of camera*1 Fig.1-7 AC Adapter  ND filter (Used when the screen is highlighted) Fig.1-8 ND filter 1.2 Camera assembly 1.2.1 Open the tripod As shown in figure 1-9，the height of the tripod is recommended to be directly opposite the center of the screen or close to the height of the viewer.

  • Page 10: Lens Installation

    Calibration Pro User Manual Fig.1-10 Head Installation Finished installation as shown in figure 1-11. Fig.1-11 Head installation completed 1.2.3 Lens Installation (1) Following Fig.1-12 arrow direction, toggle the release lever of the heads to the appointed position. (2) Adjust the lens direction consistent with the head.
  • Page 11 Calibration Pro User Manual Fig.1-12 Lens installation Fig.1-13 Lens installation completed 1.2.3.2 CCM6000 lens installation Note: This installation operation needs to be carried out in a dust-free environment.

  • Page 12: Camera Installation

    Calibration Pro User Manual Fig.1-14CCM6000 1.2.4 Camera Installation 1.2.4.1 Canon Camera Installation (1) Rotate and remove the lens cover and the body cover. (2) Camera Installation: as shown in figure 1-15. Firstly, to align the red or white mark between the lens and the camera; secondly, pushing the lens into the camera;...
  • Page 13 Calibration Pro User Manual (4)Camera installation is complete (as shown in figure 1-17). Connect the camera to the computer via USB cable, and now you can begin to calibrate. Fig.1-17 Installation completed 1.2.4.2 CCM6000 Installation The camera is connected with the connecting piece,connecting piece is locked with the buckle at the top of the holder(as shown in figure 1-18).

  • Page 14: Installation And Un-Installation

    Calibration Pro User Manual 1.3 Installation and un-installation 1.3.1 Installation 1) Double-click the installation icon select a language Fig.1-19 Installer language Enter welcome interface. Fig.1-20 Welcome page Select Quick Install, click Next, and the software will automatically complete the installation;...
  • Page 15 Calibration Pro User Manual Fig.1-21 Choose install location 4) Choose components. Fig.1-22 Choose components 5) Finish installation 。...

  • Page 16: Un-Installation

    Calibration Pro User Manual Fig.1-23 Setup completion Software can be run directly after installation, desktop shortcut will be generated automatically by system, right-click and choose [Run as administrator] to run the client application 1.3.2 Un-installation Internal uninstall application: select [ all application→ calibration→ uninstall ] from the start menu, software can be removed automatically.

  • Page 17: Calibration Instruction

    Calibration Pro User Manual 2. Calibration Instruction 2.1 Software interface When open the software, the main interfaces (shown as Fig.2-1) will appear. Preview interface is for server application and operation interface is for client application, also work when you separately run them on two computers.

  • Page 18: Homepage

    Calibration Pro User Manual 2.2 Homepage Fig.2-3 Homepage 2.2.1 New project New Integrated：Open new integrated wizard. New Cabinet：Open new Cabinet wizard. New Subscreen：Open new subscreen wizard Import From: Open import wizard， when calibration multiple screens with the same specification. 2.2.2 Language and help 中文：Switch to Chinese.

  • Page 19: Open Project

    Calibration Pro User Manual 2.2.3 Open Project Recent projects will be shown here, you may click to opem them. Browse：Open calibration project file you choosed. Integrated calibration 3.1 Configure the screen Set the right parameters for display through LEDVISION , then send and save the setting data to the receiver card.
  • Page 20 Calibration Pro User Manual Fig.3-2 Project wizard-2 This step is about the senders and receivers of the screen, the software will detect them automaticly. If they are detected as expected and then click ‘Next’. Step 3 Fig.3-3 Project wizard-3 Select the camera model. When the camera is not connected, the Canon camera is selected by default.
  • Page 21 Calibration Pro User Manual Calibration mode：Brightness、Chroma and Repair Seam Only，The receiving card program supports chip low brightness calibration, and the chip low brightness calibration check cabinet can be checked. Step 5 Fig.3-5 Project wizard-5 Fig.3-6 Project wizard-5 The Whole Screen project wizard -4（Fig.3-6 ） dialog cabinet contains the following items：...
  • Page 22 Calibration Pro User Manual simple screen。 Grid module： Check if there is a difference between the left 、right Pixel Pitch and the upper 、 lower Pixel Pitch on the screen. COB Module: Select the check cabinet if the screen to be calibrated is COB display screen.
  • Page 23 Calibration Pro User Manual Step 6 Fig.3-7 Whole Screen Project wizard-6 Edge Reserved is used when the lamps on the edge of the screen is blocked. Step 7 1. The wizard 6 is shown like 3-8 when the sender is not connected receiver or no sender connected or only one sender connected.
  • Page 24 Calibration Pro User Manual Fig.3-9 Project wizard 6 1) Sender Row/Column: Set the sender row and column according to the actual sender layout. 2) Sender Width/Height: Current selected sender width or height. click next to entry wizard 7. Step 7 It is shown as fig.3-9...

  • Page 25: Connect To Server

    Calibration Pro User Manual 3.3 Connect to Server Running calibration, select [ setting -> Connect ] to enter setting page, and input the correct server IP. (Running CMD.exe and input [ ipconfig ] then you can get this computer IP address is 127.x.x.x). The server port is the same as the client (the server...

  • Page 26: Screen Display

    Calibration Pro User Manual Fig.3-13 Successful Connection Tip CaliProServer support up to 64 senders. 3.4 Screen display 3.4.1 Display with sender card While the server is connected, the client will detect sender card and receiver card sender control mode automatically. Result will be shown as Fig.3-14...

  • Page 27: Sender Card Setting

    Calibration Pro User Manual Fig. 3-14 sender control mode Detect: detect sender card and receiver card immediately. When you have more than 1 sender card, you should set as section 3.4.2.1. 3.4.1.1 Sender Card Setting Clicked [ Sender Card Setting ] to set sender cards. As Fig. 3-15:...
  • Page 28 Calibration Pro User Manual Fig. 3-15 Sender Card Setting Widzard-1 NOTE: Block Setting---------1) by Size Divide the screen by the size of block; 2) by Blocks When selected [ Rule Layout ], divide the screen according to rows and columns , otherwise average divide the screen width;...

  • Page 29: Basic Parameter Setting

    Calibration Pro User Manual You can drag the sender card in the left side to exchange with others, you can also resize the sender card(s) with dragging the boundary in terms of module size. 3.5 Basic parameter setting Fig. 3-17 Basic Parameter Setting Window 1）Corresponding to select the send mode and the calibration mode.
  • Page 30 Calibration Pro User Manual 3-20 for more details on tablecloth settings. Fig. 3-19 Tablecloth Setting Window 5）Change tablecloth location to set the screen offset. 6）Block Resolution: The numerical size is determined by camera resolution. 7）when using canon camera: We suggest the width×height of a single photo is 150×100.
  • Page 31 Calibration Pro User Manual Fig.3-20 Block Preview Window...
  • Page 32 Calibration Pro User Manual Select [ block preview ] → [ block map ], and choose one block from it as camera adjustment area. At this time, the corresponding area on LED screen will be selected and lighted (present in the form of white frame plus LED tricolor).
  • Page 33 Calibration Pro User Manual the acquisition grayscale setting is displayed; a.Color calibration:Showing the collection setting of highlight gray scale, "Highlight Collection": displaying the collection gray scale 233 and the collection gray scale 217, with the collection gray scale 217 checked by default, which can be unchecked only for low-highlight calibration.
  • Page 34 Calibration Pro User Manual Pick Gamma Setting:Set the gamma value of the current actual acquisition, the default value is 64. Initial Value:Set the coefficient collected by the initial low brightness calibration, The default value is 16.,The higher the initial value, the higher the graying brightness.

  • Page 35: Camera Preparation

    Calibration Pro User Manual Initial coefficient setting: set the initial coefficient of each time according to the number of times of acquisition. The default values are 0, 0.1, 0.2, 0.3; Fig.3-26 Multi grayscale capture 3.6 Camera preparation 1. To set up the camera 2.

  • Page 36: Camera Adjustment

    Calibration Pro User Manual inserted,Select [ connect camera ] in the tool bar,The prompt "Camera not authorized, connection failed" pops up. 4. Select [ start EVF ], which is in the tool bar too. Its icon will be changed to after that.
  • Page 37 Calibration Pro User Manual Fig.3-28 2）CCM: Connect CCM1600 or CCM6000 camera, as shown in Figure 3-29, check [Lock the viewfinder], check [Display at intervals] when there is a jumping point, and arbitrarily select a certain color of red, green, blue and white. At this time, the corresponding partition at the top of the screen will display the corresponding color at intervals according to the jumping point size;...
  • Page 38 Calibration Pro User Manual Fig.3-29 Auto adjustment...

  • Page 39: Auto Adjustment

    Calibration Pro User Manual 3.7.2 Auto adjustment 3.7.2.1 canon auto adjustment Click "Start automatic metering", and the program will automatically adjust the camera parameters to make the exposure normal. When the light spot sizes do not meet the requirements in the automatic metering process, the red, green and blue light spot sizes are displayed in red letters on a yellow background.

  • Page 40: Second Calibration Auto Adjustment

    Calibration Pro User Manual Fig.3-31 Auto adjustment 3.7.2.2.2 Second Calibration auto adjustment Capture Gray Setting Dialog ,Check the second calibration: 1) Brightness Calibration,Select acquisition gray-scale -1, click the "Start Auto Adjust" button to adjust the brightness, After the adjustment is completed, calibrate...
  • Page 41 Calibration Pro User Manual Fig.3-32 Brightness 2) Brightness and Chroma Calibration,Select acquisition gray-scale -1, click the "Start Auto Adjust" button to adjust the brightness. After the adjustment, calibrate the acquisition gray-scale -1. After the calibration is completed, enable the calibration.

  • Page 42: Chip Low Brightness Auto Adjustment

    Calibration Pro User Manual Fig.3-33 Chroma 3.7.2.2.3 Chip Low Brightness auto adjustment 1)Single graysacle iterative capture calibration,Click the "Start Auto Adjust" button, the software will send the gamma value, initial coefficient, enable chip low brightness calibration, and start camera adjustment.
  • Page 43 Calibration Pro User Manual Fig.3-34 Single graysacle iterative capture 2)Multi grayscale capture,Select the acquisition times as 1, click the "Start Auto Adjust" button, the software first sends the gamma value and the initial coefficient for the first time, and enables chip low brightness calibration to start camera adjustment.

  • Page 44: Manual Adjustment

    Calibration Pro User Manual Fig.3-36 Collect Grayscale and Camera parameters For the use of ccm6000 camera calibration file, Insert the encrypted U disk of the currently used camera. On the camera adjustment page, select the lens model, aperture and ambiguity actually used by the current camera, and the software will automatically apply the corresponding calibration file.
  • Page 45 Calibration Pro User Manual Fig. 3-37 Camera Adjustment a. When validation result shows “ Normal”, and the lamp size is less than 150, it prompts with red font, orange yellow background in . When it happens, please tune the aperture to make the real-time image blurred, then re-metering;...

  • Page 46: Ccm Adjustment

    Calibration Pro User Manual 3.7.3.2 CCM adjustment 3.7.3.2.1 screen manual adjustment Regular Connect CCM1600 or CCM6000 camera, select in "Camera Adjustment" and enter the manual metering interface, as shown in Figure 3-38-A and 3-38-B. Figure 3-38-A Figure 3-38-B a.bright calibration : manual metering has three components: red, green and blue.
  • Page 47 Calibration Pro User Manual Figure 3-39 3.7.3.2.2 Second Calibration manual adjustment 1）Brightness Calibration,Click "R", select acquisition times - 1, click "Test" button, the software will collect a photo for analysis and prompt the test results, select acquisition times - 2, click "Test" button, start calibration, the software will collect a photo for analysis and prompt the test results.

  • Page 48: Manual Adjustment

    Calibration Pro User Manual for analysis and prompt the test results. 3.7.3.2.3 Chip Low Brightness Calibration manual adjustment 1)Single graysacle iterative capture calibration,Select "R\G\B" in sequence, click the "Test" button, the software will send the gamma value and initial coefficient, and enable the chip low brightness calibration for photographic analysis.

  • Page 49: Effect Debug

    Calibration Pro User Manual  Increase brightness percentage Repeat step1-step3, to confirm picture histogram meet the requirements. Note: Parameters change together with camera adjustment. Please save new setting parameters after the accomplishment of shutter adjustment. 3.8 Effect Debug Project wizard-5, check the chip low brightness calibration, select single gray scale iterative acquisition calibration, and the menu bar displays the effect debugging page, including automatic adjustment and manual adjustment pages.

  • Page 50: Shooting Photos Part

    Calibration Pro User Manual 3.9 Shooting photos part 3.9.1 Shooting photos part 1.Select one block from the [Shooting photos] in the partition map, then click [ Monitor ]. 2. Adjust the camera to make the screen displayed area position in the preview area of the white cabinet of Tab [ shooting photos ] .
  • Page 51 Calibration Pro User Manual 5.The calibrated object can be modified as [Spare] only when at least one block in the partition map of the conventional screen has accomplished analysis. Click [Modify]. In the pop-up [Calibration Object Setting] window, you can select [Spare], and the analysis file and photo file of the Spare object can be loaded automatically.
  • Page 52 Calibration Pro User Manual A. select the gray scale to be collected in the gray scale list, as shown in figure 3-36. 、 figure 3-43. B. Secondly, move the mouse to the partition map on the right, click to select the photo partition, as shown in Figure 3-44, and a white border will appear on the corresponding screen.

  • Page 53: Effect Evaluation

    Calibration Pro User Manual Fig.3-44 Switching to Spare 3.9.2 Effect Evaluation 1、The brightness of the whole screen is Calibration,When a partition is collected and analyzed in the project, the effect evaluation button is displayed on the upper right corner of the menu bar, as shown in the following figure:...
  • Page 54 Calibration Pro User Manual Fig.3-45 effect evaluation 2、Click “Effect Evaluation” button,Enter the effect evaluation setting window, where x and y are the starting point coordinates of the effect evaluation area. The default (x, y) coordinates are (0,0). The "width and height of the evaluation area" are the width and height of the actual area to be evaluated, and the default is the width and height of the partition;...

  • Page 55: Generate Coefficient

    Calibration Pro User Manual Fig.3-46 evaluation report 3.10 Generate coefficient 3.10.1 Brightness extraction Start brightness extraction for images with clicking [ start analysis ] on [ shooting ] after shooting. (when completed the analysis of corresponding RGB images, a check...

  • Page 56: Generate Coefficient

    Calibration Pro User Manual Fig. 3-47 Start Analysis Analysis going with shooting can save lots of time if the computer has a good configuration. 3.10.2 Generate coefficient 1. The extracted brightness maps can be checked by selecting [ Coefficient ]...
  • Page 57 Calibration Pro User Manual generate coefficient Fig. 3-48 2.Cob module chroma calibration, brightness map display has X, Y and Z switching display, as shown in Figure 3-49. Fig. 3-49 chroma lumi graphs...
  • Page 58 Calibration Pro User Manual 3. For second brightness calibration, select the gray level 200-1 and 200-2 to display the brightness calibration interface; For second chroma calibration, select the gray level 200-1 to display the brightness calibration interface; Select the gray level 200-2 to display the chroma calibration interface.
  • Page 59 Calibration Pro User Manual and b operation steps. a. If there is no intelligent module in the cabinet, click "Save Coefficient" to pop up two drop-down buttons of Send Coefficient to All and Send Coefficient to Designated Area, and click Send Coefficient to All to send the calibration coefficient to all receiving cards;...

  • Page 60: Eliminate Camera Dust And Worms

    Calibration Pro User Manual Figure 3-52 send coefficient to specific area 8. After saving the coefficient to receiver, click [ Calibration by Receiver Card ] to enable calibration. (please make sure all the receiver cards have been detected before saving);When the receiving card supports low-gray calibration, the check cabinet "Enable low-light calibration"...
  • Page 61 Calibration Pro User Manual by Generate Coefficient. This option is not checked by default. 3. Manual Mark: After generating lumi graphs, right click the worms or camera dust area on the lumi graphs, choose option on the pop menu. 4. Introducing Pop Menu: (1) Add Dirty: Take the mouse pint as the center and automatically select a rectangular border with 20x20 pixel.

  • Page 62: Single Cabinet Calibration

    Calibration Pro User Manual 4. Single cabinet calibration 4.1 Create single cabinet calibration Step 1/2/3: New Cabinet Open the software, select the [ ] to create a calibration (shown as Fig. 3-4).Input the project’s name and click [ next ] to entry Cabinet project wizard-1.

  • Page 63: Capture Gray Setting

    Calibration Pro User Manual Step 3: cabinet project wizard-5 Fig. 4-2 cabinet project wizard-5 cabinet project wizard-2 includes below settings (Shown as Fig. 4-2): Prefix: Project name. cabinet count: Cabinet amount of the project. Name Case: “cabinet Number”, “Row-Col” and “Col (ABC)-Row”, you can chose different naming methods.
  • Page 64 Calibration Pro User Manual default value is 3. Step size setting: set the step size required for each time according to the acquisition times, and the default is 1, 2, 2. Fig.4-3 Single graysacle iterative capture Ⅱ.Multi grayscale capture: Pick Gamma Setting:Set the gamma value of the current actual acquisition, the default value is 64.

  • Page 65: Shooting Process

    Calibration Pro User Manual Fig.4-4 Multi grayscale capture 4.3 Shooting process 4.3.1 Camera adjustment Camera adjustment refers to section 3.6, 3.7. 4.3.2 Effect Debug Effect debug refers to section 3.8.

  • Page 66: Image Capturing

    Calibration Pro User Manual 4.3.3 Image Capturing 4.3.3.1 Regular screen Image Capturing Fig. 4-5 single cabinet shooting 1. Click the [ Batch Shoot ] button, and start shooting from the first cabinet. 2. After analysis completed ( Fig.4-4 ,when three colors present √, it means that all the analysis are completed), the correct coefficient will be auto sent to receiver card (By default, the coefficient will be sent to receiver card automatically.

  • Page 67: Chip Low Brightness Image Capturing

    Calibration Pro User Manual Fig.4-6 Analysising Fig.4-7 Finished 4.3.3.2 Chip Low Brightness Image Capturing 4.3.3.2.1 Single graysacle iterative capture Image Capturing 1、Click the "Shoot" button, the software will first send the acquisition gamma,...

  • Page 68: Multi Grayscale Capture Image Capturing

    Calibration Pro User Manual initial coefficient, enable the chip low light calibration, and then conduct the first photo analysis. After completing the first acquisition analysis, a coefficient of the first acquisition will be generated, and the acquisition times will be automatically switched to the next acquisition times.

  • Page 69: Reference Model

    Calibration Pro User Manual calibration will automatically start calibration; Click OK on the pop-up cabinet, and it will automatically jump to the next cabinet. You can check the calibration effect by switching different colors. 4 、 Click Modify to set the corrected brightness of the target gray scale. The corrected brightness of the current target gray scale is applied to the cabinet that is corrected late。...

  • Page 70: Coefficient Fusion

    Calibration Pro User Manual Fig.4-10 Reference Model setting 4.3.5 Coefficient Fusion 4.3.5.1 Regular screen Coefficient Fusion This option is use for solve the vignetting. Not checked by default. Number of Cabinet: The number of cabinet is 8 by default. The fusion coefficient is not applied to the first n count, it is generated after finish the nth and apply to the subsequent cabinet, the first n count need to be send coefficient anew.

  • Page 71: Chip Low Calibration Coefficient Fusion

    Calibration Pro User Manual Fig.4-11 Coefficient Fuseion Setting 4.3.5.2 Chip Low Calibration Coefficient Fusion The coefficient fusion setting is enabled by default. The number of fusion cabinet n is 9 by default. The fusion coefficient is not applied to the first n cabinet. After the calibration of n cabinet, the fusion coefficient is generated and applied to the subsequent calibration cabinets.

  • Page 72: Calibration Log

    Calibration Pro User Manual Fig.4-12 Parameter Setting 4.3.6 Calibration Log The calibration log will log the process and excetion during calibrating in the cabinet project. 1.Plan Cabinet: Is same as the number of cabinet list. 2.Remain Cabinet: Plan Cabinet – Calibrated Cabinet.
  • Page 73 Calibration Pro User Manual Fig.4-13 Calibration Log...

  • Page 74: Deseam Setting

    Calibration Pro User Manual 5. Deseam Setting 5.1 Fuction Intrudction Deseam is to minimize the physical seam between cabinets(or modules). After shot the screen and analyzed the photos, the software will automatically adjust the luminance of the pixels on the edge to benefit the display effect of LED screen.
  • Page 75 Calibration Pro User Manual Fig.5-1 Deseam Setting The interface of deseam setting is shown in Fig.5-1.

  • Page 76: Effect Setting

    Calibration Pro User Manual 6. Effect Setting 6.1 Effect setting overview Effect setting is used for adjusting calibration effect and fixing screen flaws after calibration. The effect options will vary with your selections ( COB Module) in the Whole Screen project wizard-4 dialog cabinet. There is an effect description appearing below every option.
  • Page 77 Calibration Pro User Manual Fig. 6-2 Effect Setting-2 By default, check to ensure interchangeability after calibration, eliminate dirt spots and ensure no ambient light. 2)New project wizard, Check "COB module". a.Canon camera,the advanced setting dialog cabinet is as shown in Fig.6-3.

  • Page 78: Turn On "Eliminate Differ

    Calibration Pro User Manual Fig. 6-4 Effect Setting-4 6.2 Turn on “Eliminate Differ” “Eliminate Differ” option will eliminate the discrepancy between different calibrated blocks. This option will take effect after generating a new “Brightness Chart” under “Coefficients” page. 6.3 Eliminate vignette “Eliminate Vignette”...

  • Page 79: Eliminate Colored Moire

    Calibration Pro User Manual 6.6 Eliminate Colored Moire “Eliminate Colored Moire” will eliminate the colored moire caused by calibration acquisition. After modifying the item, you need to perform the analysis again. Fig. 6-4 Effect Setting-4 6.7 Dead Lamp The dead Lamp is the proportion of the number of dead lights on the screen to the number of lights on the screen, and the unit is one thousandth.

  • Page 80: Chroma Calibration

    Calibration Pro User Manual Fig.7-1 Select “Brightness and Chroma” Calibration 7.2 chroma calibration 2． 1)Switch to [ Coefficients ] page. 2)Click [ Brightness Chart ]. Skip this step if it’s a cabinet calibration. 3)Click [ Color Gamut.. ], which shown as Fig. xxxx & Fig. xxxxx.
  • Page 81 Calibration Pro User Manual Fig.7-2 Setting entrance of whole screen calibration Fig.7-3 Setting entrance of single cabinet color gamut...

  • Page 82: Chroma Calibration

    Calibration Pro User Manual 7.3 chroma calibration 7.3.1 canon calibration Fig.7-4 color gamut setting With the chromemeter, select [ Auto Measure ], then input the brightness and chroma data manually before calibration. Without the equipment, just skip to c). After automatic measurement , collect the white data to verify.
  • Page 83 Calibration Pro User Manual Color temperature： If you need to change the color temperature, you can uncheck [white] of [ Auto Calculate ], then input the target color temperature, built-in algorithms will automatically calculate the color coordinates. f)Approx value: when the target color gamut over the original color gamut, you can click [Approx value], algorithms will automatically calculate and limit the exceeded part in the nearest original color gamut.

  • Page 84: Tools

    Calibration Pro User Manual 8. Tools 8.1 coef Rotate Tools You can rotate the cabinet or screen coefficient, which is clockwise by default 1，By Cabinet:Can carry out the cabinet or set the cabinet width and high resolution. 2，By screen:Can set the screen width and high resolution of the cabinet.

  • Page 85: Gamma Test

    Calibration Pro User Manual body calibration coefficient after repair; 7，Crosshair strength coefficient, which is displayed as 1 by default, can be modified according to actual situation. Set, click Start, the software automatically generates the cabinet calibration coefficient after repair, click Export Reference Model, and export the Current crosshair model file.
  • Page 86 Calibration Pro User Manual 7，Measurement range, the default display is 0- the current maximum gamma value, which can be modified manually. 8，Measuring step, setting measuring step. 9，Measure according to the gamma meter, and use the current screen reference gamma meter to measure.
  • Page 87 Calibration Pro User Manual Fig.8-4 data manger 8.4 Coef Adjust Solve the problem of obvious light dark color difference when the whole screen calibration backup module is replaced to other areas. 1，Reference area coefficient file: import original full screen calibration coefficient.
  • Page 88 Calibration Pro User Manual Fig.8-5 coef adjust 9. Suggestion on calibration 1. Shift the camera to M mode. 2. Gray scale and brightness can not be modified at random while shooting. Because changes will have impacts on RGB color photos;...
  • Page 89 Calibration Pro User Manual 10. FAQ Q: Failed to detect receiver card. A: 1. Ensure the stable connection between hardwares. 2. Improve the frame time. 3. Select the right net card under the drop down list. Q: Can not open after installation? A: 1.
  • Page 90 Calibration Pro User Manual software, and check all plug-ins of the software when installing. Q: Failed to shoot the photos. A: 1. Confirm that the camera model is supported by the software (Software currently only support part of the Canon camera, please contact the technical support for details), please pay attention that the EOS 7D is not the same as the EOS 7D MARK 2.
  • Page 91 Calibration Pro User Manual Reset the correct camera parameters on camera adjustment page. Shake: 1. Make sure shooting system stability. 2. Close the lens and the camera stabilization function. Q: Screen brightness/saturation reduced after calibration. A: Brightness calibration makes the screen evenly by reducing the lighter point brightness, thus the screen brightness will decline after calibration.
  • Page 92 Calibration Pro User Manual and then you will shooting in a slightly out of focus condition (But this measure requires the focusing error can not be too large). Enable the skip point function to improve the spacing if you need.
  • Page 93 Calibration Pro User Manual...
