6. Select YES if you want to include the tape drive in the demo. Select NO if
you do not want to include the tape drive in the demo.
→ ←
Use or .
• If you select YES, the CHM pushes the cartridge all the way into the drive.
• If you select NO, the CHM inserts the cartridge into the drive slot, but
does not push the cartridge all the way into the drive.
The tape will not automatically eject the cartridge.
7. The system begins the demo and displays this screen:
DRIVE DEMO:
Total Cycles: N
Status: Move NN - NN
N
NN- NN
To stop the demo, press Escape and Enter.
Note – If you cannot press the Escape or Reset keys, power cycle the tape
library.
SPARCstorage Library Installation and User's Guide—June 1995
Indicates the number of cycles that have run so far.
Indicates the source and destination element indexes of
the current move.
