LCD Interface
LCD Interface Mode is required when you want to control the motions of the
CHM though the display panel. For example, diagnostics can be performed
that test individual motions, such as picking and placing cartridges from
specific locations.
Note – You must be in LCD interface mode to run certain tests in the
Maintenance Menu.
1. Disable security.
2. Select the Interface Menu by pressing
3. Select the Control Mode Menu by pressing
4. Select LCD Interface mode by pressing
You can now execute commands in the the Maintenance Menu.
SCSI Interface Mode
In the SCSI Interface mode, the host computer system issues SCSI commands to
the tape library to specify how cartridges are loaded and unloaded from the
removable cartridge holder and to access the tape drives.
To get the tape library to SCSI Interface mode:
1. Disable security.
2. Select the Interface Menu by pressing
3. Select the Control Mode Menu by pressing
4. Select SCSI Interface by pressing
SPARCstorage Library Installation and User's Guide—June 1995
↓ ↑
or , then Enter.
↓ ↑
or , then Enter.
↓ ↑
or , then Enter.
↓ ↑
or , then Enter.
↓ ↑
or , then Enter.
↓ ↑
or , then Enter.
