Menu Function - ITech IT7900P Series User Manual

Digital IO-7: TRIG2
Product model
Serial number
Information
Software version
MAC address

7.1.1 Menu function

Set OFF Mode Status
This parameter is used to set the status after the power output is off.
⚫
⚫
⚫
Set the keyboard sound
This item can set the key sound state. If in ON mode, then when you press a
Function setting of pin 7
Reverse
Fun
AC
DC
Freq
List
Display the instrument model.
Display the serial number.
Display the control board version.
MAC address
Select to High-Z, After the power output is Off, the dc impedance between
the terminals of the power supply is high, and the resistance value varies
with different models.
Select to Short, When the power output is Off, the terminals of the power
supply are short-circuited, the voltage is 0.
Select to Open-Z, After the power output is Off, the power supply is in open
mode, and the internal circuit and external load of the power supply are
disconnected by relay.
Copyright ©ITECH Electronic Co., Ltd.
System-Related Functions
trigger signal.
(This configuration is displayed only
when the IO pin is set to Trigger1-out)
On/Off
⚫ Trigger1-out
⚫ Trigger1-in
⚫
Input
⚫
Output
On/Off: When On is selected, a trigger
signal is output when AC amplitude
changes. The accuracy of voltage change
is 100mV and is not restricted by phase.
(This configuration is displayed only
when the IO pin is set to Trigger2-out)
On/Off: When On is selected, a trigger
signal is output when the DC amplitude
changes, and the voltage change
precision is 100mV.
(This configuration is displayed only
when the IO pin is set to Trigger2-out)
On/Off: When On is selected, a trigger
signal is output when the frequency
changes.The accuracy of frequency
change is 0.1Hz
(This configuration is displayed only
when the IO pin is set to Trigger2-out)
On/Off: When On is selected, the List
generates a trigger signal and outputs a
trigger signal.
(This configuration is displayed only
when the IO pin is set to Trigger2-out)
