ITech IT7900P Series User Manual page 112

AC
Configuration setting for AC mode
Config
Balance control
Voltage AC
Frequency
Phase control
Waveform
Dimming
AC+DC
Configuration setting for AC+DC mode
Config
Balance control
Voltage AC
Voltage DC
Frequency
Waveform
Dimming
Copyright ©ITECH Electronic Co., Ltd.
Vac: output voltage of AC, range from 0-
10% of full scale
Freq: frequency value
Only displayed in 3-phase mode.
Balance control in 3-phase mode.
If select On, the output of ABC phase is
synchronous.
If select Off, the output is not balanced.
Output voltage
Vac: output voltage of AC, range from 0-full
scale
Slew Rate: Slope , range from 0.0001-
5000V/ms
Freq: output frequency, range from 16-
150Hz
Slew Rate: slope, range from 0.00001-
5000Hz/ms
Phase difference between AB and AC, only
valid in balance control is Off state.
AB: Phase difference between A and B.
AC: Phase difference between A and C.
Selece and edit the output wave type. For
detailed introduction please refer to 5.6
waveform selection.
Status: Dimming function switch.
Edge: select front edge or back adge
Phase: phase control, range from 0-180°
Only displayed in 3-phase mode.
Balance control in 3-phase mode.
If select On, the output of ABC phase is
synchronous.
If select Off, the output is not balanced.
Output voltage
Vac: output voltage of AC, range from 0-full
scale
Slew Rate: Slope , range from 0.0001-
5000V/ms
Output voltage of DC, range from 0-10% of
full scale
Slew Rate: Slope , range from 0-5000V/ms
Freq: output frequency, range from 16-
150Hz
Slew Rate: slope, range from 0.00001-
5000Hz/ms
Selece and edit the output wave type. For
detailed introduction please refer to 5.6
waveform selection.
Status: Dimming function switch.
Edge: select front edge or back adge
Phase: phase control, range from 0-180°
System-Related Functions
