1.7 Configuration Menu Function

This section gives an overview of the configuration menu of the this series
instrument.
The configuration parameters are different under Source mode and Load mode,
please select the mode at first.
The procedures to operate the configuration menu are as follows.
1. Press the composite keys [Shift]+[V-set] (Config) on the front panel to enter
2. Press [Enter] to select the desired menu item.
3. After finishing the menu setting, press [Enter] key to save the setting.
The descriptions of configuration menu of the power supply are listed in the ta-
ble below.
Config
the configuration menu.
The VFD shows configuration menu items and each menu item is marked
with a number. The user can use knob to scroll pages to view the other menu
items.
Enter the parameter setting interface of this menu item.
Press [Esc] key to return to the previous menu level.
Configuration menu of the power supply
Mode
V-Rise Time/I-Rise Time
= 0.001s
Copyright © Itech Electronic Co., Ltd.
CC/CV priority mode setting
Constant voltage loop priority mode
CV
Speed= High/Low
Constant current loop priority mode
CC
Speed= High/Low
Displays the voltage or current rise time
setting according to the selected priority
mode. If CC priority mode is selected,
Quick Reference
Loop response
speed setting:
high speed /
low speed
Loop response
speed setting:
high speed /
low speed
