ITech IT7900P Series User Manual page 104

External
programme
Remote sense
On/Off phase
Measurement
Menu of Load mode:
Device operation
mode
Load
Phase mode
Freq limit+
Freq limit-
Exception
External analog function:
Status
Mode
Monitor phase
U ratio
I ratio
Set the sense function state.
Mode
On-mode
Off-mode
Set the measurement speed
Lower
（1000ms）
Slow（500ms）
Medium
（300ms）
Fast（150ms）
Filter
Set the instrument mode
Volt Source: voltage source load
Load: load mode
Set the AC input mode
1-Phase
3-Phase
Copyright ©ITECH Electronic Co., Ltd.
System-Related Functions
Set the upper limit
frequency.
Set the lower limit of output
frequency.
Set the output mode when the
frequency lock fails:
Output Disable: stop output
⚫
⚫ Limit: Output according to the
set frequency.
Set the ON/OFF state
AM: Adjust the amplitude
Amplifier: Real-time output and
power Amplifier.
Select the phase to monitor.
This cannot be set in single phase
mode.
The external program ratio of
voltage.
The external program ration of
current.
On: Enable the remote sense
Measurement
Off: disable the sense function
Output on phase control
Phase: setting the phase
Imm: immediately
Output off phase control
Phase: setting the phase
Imm: immediately
Lower mode, measuring every
1000ms
Slow mode, measuring every
500ms
Medium mode, measuring every
300ms
Fast mode, measuring every
150ms
Whether to turn on the filter during
measurement.
Single phase
Three phase
of output
102
