Configuration Menu Function - ITech IT-M3900C Series User Manual

Flag
Shift
SRQ
CW

1.7 Configuration Menu Function

This section gives an overview of the configuration menu of the this series
instrument.
The procedures to operate the configuration menu are as follows.
1. Press the composite keys [Shift]+[V-set] (Config) on the front panel to enter
2. Press [Enter] to select the desired menu item.
3. After finishing the menu setting, press [Enter] key to save the setting.
The descriptions of configuration menu of the power supply are listed in the ta-
ble below.
Config
Function
Description
Using composite
function key
Indicates that the
internal status re-
quest event occurs.
The power supply is
in a state of con-
stant power output.
the configuration menu.
The VFD shows configuration menu items and each menu item is marked
with a number. The user can use knob to scroll pages to view the other menu
items.
Enter the parameter setting interface of this menu item.
Press [Esc] key to return to the previous menu level.
Configuration menu of the power supply
Mode
Copyright © Itech Electronic Co., Ltd.
Flag
Prot
Trig
-
CC/CV priority mode setting
Constant voltage loop priority mode
CV
Quick Reference
Function Description
The instrument enters the
protection state.
The instrument is in a state
of waiting for a trigger.
-
10
