Digital IO-3: PS
Digital IO-4: SYNC
Digital IO-5:
ON/OFF Status
Digital IO-6: TRIG1
Copyright ©ITECH Electronic Co., Ltd.
⚫
Function ⚫
⚫
Function setting of pin 3
On/Off, Select Invert or not under the
Reverse
IO Settings. If setting to ON, it means
the valid signal is reversed.
⚫
Function ⚫
⚫
Function setting of pin 4
On/Off, Select Invert or not under the
Reverse
IO Settings. If setting to ON, it means
the valid signal is reversed.
⚫
⚫
Function
⚫
⚫
Function setting of pin 5
On/Off, Select Invert or not under the
Reverse
IO Settings. If setting to ON, it means
the valid signal is reversed.
⚫
Function ⚫
⚫
Function setting of pin 6
On/Off, Select Invert or not under the
Reverse
IO Settings. If setting to ON, it means
the valid signal is reversed.
⚫
⚫
Function
⚫
⚫
On/Off: When On is selected, a trigger
signal is output when AC amplitude
changes. The accuracy of voltage change
AC
is 100mV and is not restricted by phase.
(This configuration is displayed only
when the IO pin is set to Trigger1-out)
On/Off: When On is selected, a trigger
signal is output when the DC amplitude
changes, and the voltage change
DC
precision is 100mV.
(This configuration is displayed only
when the IO pin is set to Trigger1-out)
On/Off: When On is selected, a trigger
signal is output when the frequency
changes.The accuracy of frequency
Freq
change is 0.1Hz
(This configuration is displayed only
when the IO pin is set to Trigger1-out)
On/Off: When On is selected, the List
List
generates a trigger signal and outputs a
System-Related Functions
PS Clear
Input
Output
PS
Input
Output
Sync-in
Sync-out
Input
Output
ON/OFF Status
Input
Output
Trigger1-out
Trigger1-in
Input
Output
