Instrument Introduction
The rear panel of IT7900P series 15U and above series cabinets are the same.
Take IT7945P-350-270 as an example, the rear panel is introduced as shown
below.
4
3
2
1
1: Output socket, which can be used when users need single-phase lower than
220V/10A power supply
2: Output terminals and protective cover, remove the protective cover to show
ABCN terminals and sense terminals
3: Input terminal, connected to the instrument's power supply
4: The communication interface for cabinet, the detailed diagram as follows, and
the descriptions are the same as 3U model.
23
