5.4.8. BGP

The BGP tab allows to set up peerings of the NetModule router with other Border Gateway
Protocol enabled routers.
Parameter
BGP status
AS number
Redistribute connected
routes
Redistribute local routes
Redistribute OSPF routes
Disable BGP when VRRP
slave
The neighbors tab is used to con gure all the BGP routers to peer with.
Parameter
IP address
As number
Password
Multihop
The Networks tab allows to add IP network pre xes that shall be distributed via BGP in
addition to the networks that are redistributed from other sources as de ned on the general
tab.
Parameter
Pre x
Pre x length
NB3000-Line-Hd User Manual 4.2
BGP General Settings
Speci es whether the BGP routing protocol is active
The number of the autonomous system to which the NetMod-
ule router belongs (1-4294967295)
Redistribute routes to networks which are directly connected
to the NetModule router
Redistribute routes from the NetModule router's own routing
table
Redistribute routes learned via the OSPF routing protocol
Disables the BGP protocol when the router is set to slave mode
by the VRRP redundancy protocol
BGP Neighbors
IP address of the peer router
Autonomous system number of the peer router (1-
4294967295)
Password for authentication with the peer router. If left blank
authentication is disabled.
Allow multiple hops between this router and the peer router
instead of requiring the peer to be directly connected.
BGP Networks
Pre x of the network to be distributed
Length of the pre x to be distributed
