Map control
15 Map Control
Designation
1 Zoom in
2 Zoom out
3 Center view
4 Save map
5 Switch to default mode
RA91390962 AB-V1.3.3, en
User interface | ILS, ActiveShuttle | 103
Description
→ Zoom in and out.
Notice!
The wheel button in the mouse can also be
used to zoom.
→ Zoom and center the map to the selected
coordinate.
→ Save annotations to the map to the MUS (Map
Update Server)
Map is activated.
Notice!
No job should be running while saving is in
progress.
→ Switch from editing to default mode.
The default mode allows navigation through
the map without selecting any element.
