11 Manipulation

WARNING!
Risk of injury when adjusting the bed!
► Ensure that there are no body parts between the mattress support platform elements and the mattress support
platform frame when adjusting the bed.
► Ensure that there are no body parts below the mattress support platform frame before adjusting the bed.

11.1 Siderails

The split siderails are components of the bed in contact with patient. A pneumatic spring supports the operation of the split siderails.
The nursing personnel are responsible for the siderails being raised up while the patient is in bed.
WARNING!
Risk of injury, damaging or unintentional movement of the bed due to incorrect placement of accessories or
Handset!
► Never place any accessories or Handset on the siderails in the area where keyboards are located.
► Never place Handset on the edge of siderail.
The correct placement of Handset is shown at following pictures.
WARNING!
Risk of injury due to incorrectly latched siderail!
► Ensure that siderail is secured in the upper or lower position.
WARNING!
Risk of injury due to incorrect position of siderails!
► Ensure that siderails are folded up while the patient is in bed.
SIDERAIL DESCRIPTION
Fig. Siderails
MANIPULATION
To raise siderails up:
► Grab siderail by Siderail Handle (2).
► Pull siderail up until it latches. You will hear audible „click".
To release siderails down:
► Grab siderail by Siderail Handle (2).
► Unlock siderail by pulling Siderail Release Handle (4) to yourself.
► Fold down siderail slowly.
D9U001MCX-0101_03
1 2
4
2 3
4
1. Multiboard X with LCD touchscreen
2. Siderail Handle
3. Correct Placement of Handset
4. Siderail Release Handle
