5 Technical Specification
All technical data are rated data and are subject to construction and manufacturing tolerances.
WARNING!
If Multicare X bed is used with OptiCare X integrated mattress system respect values of mechanical and elect-
rical specifications which can harm none of them!
5.1 Identification of Applied Parts (Type B)
All part of the bed (and accessories) the patient can reach are type B Applied Parts.
■ Mattress support platform frame, Covers and all Movable Parts
■ Head Board and Foot Board
■ Siderails
■ Mobi-Lift Handles
■ Handset

5.2 Scales (only version with scales)

Accuracy of displayed weight values:
■ 0,5 kg (1,1 lbs)
■ Scales Class III
5.3 Mechanical Specifications (Multicare X)
External Dimensions in Standard Bed Position (length x width)
Maximum Length of Backrest
Maximum Length of Seat Section
Maximum Length of Thighrest
Maximum Length of Calfrest
Safety Siderail Height above Mattress support platform
Dimensions of Head Siderail (length x height)
Dimensions of Foot Siderail (length x height)
Bed Extension (minimum — maximum)
Maximum Dimensions of Mattress (length x width)
Maximum Mattress Height
Clearance in Standard Position
Castor diameter
Minimum — Maximum Mattress support platform Height above
floor (without Mattress)
Ergoframe (Backrest/Thighrest)
Maximum Backrest Angle
Maximum Thighrest Angle
Maximum Calfrest Angle
Angle between Calfrest and Thighrest
Maximum Lateral Tilt Angle
Trendelenburg Angle
Antitrendelenburg Angle
Average Bed Weight (without mattress)
Bed Safe Working Load (SWL):
- Patient
- Mattress (OptiCare X)
- Accessories
- Load on the Accessories
D9U001MCX-0101_03
Parameter Value
215 cm x 105 cm
87,5 cm
26,5 cm
36 cm
38,5 cm
45 cm (maximum)
53,5 cm x 56,5 cm
100,7 cm x 46 cm
0 cm — 22 cm
214 cm x 87,5 cm
23 cm
15 cm
15 cm
44 cm — 82 cm
6 cm / 6 cm
70°
30°
38°
112°
+30°/-30°
13°
16°
224 kg
250 kg
185 kg
15 kg
13,12 kg
28,6 kg
