TILES ON THE HOME SCREEN
Tile
POSITIONING
30°
POSITIONING
25°
LOCKS
LOCKS
SCALES
120
kg
SCALES
46
BACKREST ANGLE IS IN 30°
(GREEN UPPER PART OF FIGURE = BACKREST ANGLE IN MORE THAN
30° OR EQUAL TO 30°)
BED IS IN THE MINIMUM HEIGHT
(GREEN COLUMNS ON BED PICTURE = BED IS IN THE MINIMUM HEI-
BACKREST ANGLE IS IN LESS THAN 30°
(ORANGE UPPER PART OF FIGURE = BACKREST ANGLE IN LESS THAN
BED IS NOT IN THE MINIMUM HEIGHT
(ORANGE COLUMNS ON BED PICTURE = BED IS NOT IN THE MINIMUM
NO FUNCTION IS LOCKED
AT LEAST ONE FUNCTION IS LOCKED
DISPLAYED WEIGHT VALUE THAT IS NOT MANUALLY HIDDEN IN DIS-
(THE WEIGHT VALUE IS ALSO VISIBLE ON THE PLACE OF PRIMARY
DISPLAY ON THE SCALES SCREEN)
WEIGHT VALUE IS MANUALLY HIDDEN IN DISCREET MODE
(THE WEIGHT VALUE IS VISIBLE ONLY ON THE PLACE OF PRIMARY
DISPLAY ON THE SCALES SCREEN)
Meaning
GHT)
30°)
HEIGHT)
CREET MODE
