Manipulation - LINET Multicare X Instructions For Use And Technical Description

NOTE Each bed can transport only single patient at a time and cannot be used to transport other items (except bed accessories
in secured position).
NOTE For information concerning uses other than those outlined in the "Specifications of Use" section above, please contact
LINET ®.

17.7.4 Manipulation

CAUTION!
Damage to i-Drive Power main control panel cable due to wrong cable placement!
► Ensure that the main control panel connecting cable is placed correctly.
CAUTION!
Material damage due to incorrect use!
► Do not hang anything on the main control panel and its cable!
Fig. Position of Main Control Panel
1. Safety Sense (touch sensor)
2. Main Control Panel
3. Main Control Panel Cable – correct cable placement
4. Activation Panel
D9U001MCX-0101_03
1
2
3
4
123
