18 Mattress

Multicare X bed is designed for passive and active mattresses from LINET portfolio.
CAUTION!
Incompatibility with bed due to incorrect mattress dimensions!
► Check maximum approved mattress dimensions (chapter Technical Specification).
The manufacturer recommends the use of the following mattress systems on the Multicare X bed:
PASSIVE MATTRESSES
■ CliniCare 10
■ CliniCare 20
■ CliniCare 30

18.1 Fixation of a mattress on the mattress support platform

To fix mattress on the Mattress Support Platform:
► Run three straps through the three corresponding holes in the covers of Mattress Support Platform.
► Run these three straps under the bars of the Mattress Support Platform.
► Lock the three side release buckles by connecting their male and female parts together.
To remove mattress from the Mattress Support Platform:
► Release the three buckles by pressing them from both sides and by disconnecting their male and female parts.
► Pull these three straps out of the Mattress Support Platform.
► Remove mattress from the Mattress Support Platform.
Fig. Fixation of the mattress with straps on the mattress support platform of Multicare X bed
D9U001MCX-0101_03
ACTIVE MATTRESSES
■ Virtuoso Pro (not integrated)
■ CliniCare 100 HF (not integrated)
■ OptiCare X (integrated)
