16.6 Activated Automatic Lateral Therapy

6
1
ALT
26°
CYCLES
5
5
Fig. Activated Automatic Lateral Therapy
To start a set Automatic Lateral Therapy:
► Press PLAY Icon (3).
PREPARE THE BED FOR TARING / ZEROING
• Make the bed
• Attach the required accessories
To stop a running Automatic Lateral Therapy:
• Set the bed to horizontal position
► Press STOP Icon (2).
► Adjust the bed to horizontal position by pressing
the icon .
Press Tick Icon.
►
114
2:00 2:00
2:00 2:00
15° 15°
1
25° 25°
ALT
2:00 2:00
25°
26°
NEXT MOVEMENT
1:25:10
4 3
7 8
06
ON
0:30 0:30
2:00 2:00
0° 0°
15° 15°
0:30 0:30
2:00 2:00
0°
15°
2 1
1. PAUSE Icon
2. STOP Icon (to stop a running Automatic Lateral Therapy)
3. PLAY Icon (to start a selected Automatic Lateral Therapy)
4. Countdown to next change of Lateral Tilt (remaining
HOURS:MINUTES:SECONDS)
5. Cycle counter
6. Indicator of Backrest Angle
7. Bed picture in current Lateral Tilt
8. Indicator of current direction to next phase of Automatic
Lateral Therapy
9. Indicator of Longitudinal Tilt Angle (Trendelenburg Angle
or Antitrendelenburg Angle)
DO YOU WANT TO STOP ALT?
You can set the bed to horizontal position
Fig. Confi rmation window of the Automatic Lateral Therapy
deactivation
9
22:58
25. 12. 25
2:00 2:00
25° 25°
12°
2:00 2:00
2:00 2:00
15°
25°
TEST TEST
TEST
OFF
