Status (Pop-up window)
ALT unavailable - Bed platform too
high for selected ALT angle.
Bed tilted.
OPTIMIZE function not available.
ALT paused - lift all siderails up.
ALT disabled. Bed disconnected.
Plug bed into socket.
ALT unavailable - Bed overloaded.
Remove load to use ALT.
MAX
Combined positioning limit reached.
54
Automatic Lateral Therapy cannot be
activated because of too high position of
the mattress support platform.
OPTIMIZE Mode of the OptiCare X
integrated mattress cannot be activated
because of longitudinal tilt or lateral tilt of
OK
Automatic Lateral Therapy is PAUSED
because of a siderail folded down.
Automatic Lateral Therapy has been
OK
stopped and it cannot be activated now
because the bed is disconnected from
Automatic Lateral Therapy has been
OK
stopped and it cannot be activated be-
cause the bed is overloaded.
It is not possible to increase the lateral tilt
angle or longitudinal tilt angle (Trendelen-
burg Angle or Antitrendelenburg Angle)
because of the tilt adjustment limits of the
Meaning
the Multicare X bed.
the mains power.
bed.
How to change the status
Adjust a lower position of the
mattress support platform to
enable activation of the Automatic
Lateral Therapy.
Change lateral tilt adjustment
or longitudinal tilt adjustment
towards the bed horizontal po-
sition to enable activation of the
OPTIMIZE Mode.
Raise all siderails up to enable
activation of the Automatic Lateral
Therapy.
Connect the bed to the mains
power to enable activation of the
Automatic Lateral Therapy, then
press OK.
Remove load to enable activation
of the Automatic Lateral Therapy,
then press OK.
Change lateral tilt adjustment or
longitudinal tilt adjustment to-
wards the bed horizontal position
to enable the increasing of the
lateral tilt angle or longitudinal tilt
angle.
D9U001MCX-0101_03
