13.12 Lateral Tilt

It is not possible to position Lateral Tilt with a siderail folded down without use of an additional function.
To position Lateral Tilt use:
► Multiboard X
► Lateral Tilt Foot Control
► Attendant Control Panel
Multiboard X Display shows Lateral Tilt Angle. Maximum Lateral Tilt Angle is 30 degrees.
The Maximum Lateral Tilt Angle depends on position of the mattress support platform, on position of siderails (Transfer
Mode), on how much the bed is loaded and on patient position on the bed.
The following table shows Maximum Possible Lateral Tilt Angle values in relation to the patient's weight, while lying in the
middle of the bed. Other position of the patient in the bed can decrease the Maximum Lateral Tilt Angle.
Maximum Possible Lateral Tilt Angle
90
5°
10°
15°
20°
25°
30°
Fig. Lateral Tilt Angle on
Multiboard X Display
Working Load
250 kg
225 kg
199,5 kg
170 kg
153 kg
150 kg
D9U001MCX-0101_03
