6 Technical Specification

6.1 Applied parts type B

All the accesories the patient can reach are type B applied parts.
List of type B applied parts:
► ACP Attendant Control Panel
► Handset
► Satellite controller
► Siderails
► Head board and foot board
► Mattress support platform
6.2 Mechanical Specification
Dimensions
Siderail Height Above Mattress Support Platform
Siderails Length
Maximum Mattress Height
Mattress Support Platform Dimensions (Mattress)
Mattress Support Platform Extension
Mattress Support Platform Height Adjustment
Undercarriage Clearance
Castor Diameter
Maximum Backrest Angle
Maximum Thighrest Angle
Ergoframe®
Trendelenburg
Antitrendelenburg position
Bed Weight
Maximum Lifting Pole Load
Safe Working Load (including Mattress and Accessories)
Maximum patient weight
Application environment 1, 2
Application environment 3, 5

6.3 Environment Conditions

Environmental Conditions - Operation
■ Ambient Temperature
■ Relative Humidity
■ Atmospheric Pressure
Environmental Conditions - Storage and Transport
■ Ambient Temperature
■ Relative Humidity
■ Atmospheric Pressure
D9U001AM2-0101_06
Parameter Value
220 cm x 110 cm
48 cm
146 cm
26 cm
200 cm x 100 cm
0 cm / 10 cm / 22 cm / 30,5 cm
28 cm – 80 cm (85 cm - depending on configu-
ration)
13 cm (15,5 cm - depending on configuration)
12,5 cm
70°
34°
10 cm / 6 cm
14°
14°
160 kg
100 kg
320 kg
255 kg
285 kg
10 °C — 40 °C
30 % — 75 %
795 hPa — 1060 hPa
-20°C — +50°C
20% — 90% (non-condensing)
795 hPa — 1060 hPa
