HPE ProLiant ML110 Gen10 Server User
Guide
Abstract
This document is for the person who installs, administers, and troubleshoots servers and storage
systems. Hewlett Packard Enterprise assumes you are qualified in the servicing of computer
equipment and trained in recognizing hazards in products with hazardous energy levels.
Part Number: 874623-004
Published: June 2019
Edition: 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProLiant ML110 and is the answer not in the manual?

Questions and answers

Related Manuals for HPE ProLiant ML110

Summary of Contents for HPE ProLiant ML110

  • Page 1 HPE ProLiant ML110 Gen10 Server User Guide Abstract This document is for the person who installs, administers, and troubleshoots servers and storage systems. Hewlett Packard Enterprise assumes you are qualified in the servicing of computer equipment and trained in recognizing hazards in products with hazardous energy levels.
  • Page 2 © Copyright 2017–2019 Hewlett Packard Enterprise Development LP Notices The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.

  • Page 3: Table Of Contents

    Install the PCI air baffle........................30 Remove the system air baffle......................30 Install the system air baffle........................ 31 Setup......................33 Optional service..........................33 Initial server installation........................33 HPE Installation Service......................33 Setting up the server.......................34 Operational requirements........................37 Space and airflow requirements..................... 37 Temperature requirements......................38 Power requirements........................38 Electrical grounding requirements..................
  • Page 4 Installing the optical drive option....................... 69 Storage controller options........................71 Storage controller installation guidelines................71 Installing a standup PCIe plug-in Smart Array controller (type-p)...........71 Configuring an HPE Smart Array Gen10 controller..............73 Energy pack options.......................... 74 HPE Smart Storage Battery....................74 HPE Smart Storage Hybrid Capacitor..................75 Minimum firmware versions..................
  • Page 5 Installing and enabling the HPE TPM 2.0 Gen10 Kit.............. 94 Installing the Trusted Platform Module board.............. 94 Enabling the Trusted Platform Module.................97 Retaining the recovery key/password................98 Cabling......................99 Cabling guidelines..........................99 Drive cabling............................100 LFF non-hot-plug drive cabling..................... 100 LFF hot-plug drive cabling....................101 SFF hot-plug drive cabling....................103...
  • Page 6 Power supply specifications......................135 ATX 350W non-hot-plug power supply................. 135 ATX 550W non-hot-plug power supply................. 135 HPE 800W Flex Slot Platinum Hot-plug Low Halogen Power Supply........136 Websites....................138 Support and other resources..............139 Accessing Hewlett Packard Enterprise Support................139 ClearCARE technical support......................139...

  • Page 7: Component Identification

    Component identification Front panel components Item Description Box 2 Box 1 USB 3.0 ports (2) iLO Service Port PCI fan Slim optical drive (optional) Component identification...

  • Page 8: Front Panel Leds And Buttons

    Front panel LEDs and buttons Item Description Status Definition Power On/Standby button Solid green Normal and system power LED Flashing green Performing power-on sequence Solid amber System in standby No power present Health LED Solid green Normal Flashing green iLO is rebooting. Flashing amber System degraded Flashing red...

  • Page 9: Front Panel Led Power Fault Codes

    2 flashes Memory 3 flashes Riser board PCIe slots 4 flashes FlexibleLOM 5 flashes Removable HPE Smart Array SR Gen10 controller 6 flashes System board PCIe slots 7 flashes Power backplane or storage backplane 8 flashes Power supply 9 flashes...

  • Page 10: Rear Panel Leds And Button

    USB 3.0 ports (2) USB 2.0 ports (2) NIC port 2 VGA port The Broadcom 5720-based embedded HPE 332i Ethernet LAN controller provides a PCIe 2.0 x1 host interface to the onboard NIC ports. Rear panel LEDs and button Component identification...

  • Page 11: Uid Button Functionality

    UID button functionality The UID button can be used to display the Server Health Summary when the server will not power on. For more information, see the iLO user guide on the Hewlett Packard Enterprise website (http://www.hpe.com/ support/ilo-docs). Component identification...

  • Page 12: System Board Components

    System board components Item Description Fan connector 4 for the redundant system fan Fan connector 3 for the default and redundant system fans DIMM slots 24-pin power supply connector RPSU connector Processor System battery Front I/O cable connector x4 SATA port 1 x4 SATA port 2 iLO Service Port connector Table Continued...
  • Page 13 Item Description Front USB 3.0 assembly connector x1 SATA port 9 TPM connector Fan connector 1 for the default and redundant PCI fans Fan connector 2 for the redundant PCI fan x1 SATA port 10 Controller backup power connectors (2) microSD card slot System maintenance switch Energy pack connector...

  • Page 14: System Maintenance Switch Descriptions

    System maintenance switch descriptions Position Default Function Off = iLO 5 security is enabled. On = iLO 5 security is disabled. Reserved Reserved Reserved Off = Power-on password is enabled. On = Power-on password is disabled. 1, 2, 3 Off = No function On = Restore default manufacturing settings Reserved —...
  • Page 15 Item Description Example Capacity 8 GB 16 GB 32 GB 64 GB 128 GB Rank 1R = Single rank 2R = Dual rank 4R = Quad rank 8R = Octal rank Data width on DRAM x4 = 4-bit x8 = 8-bit x16 = 16-bit Memory generation PC4 = DDR4...

  • Page 16: Dimm Slot Locations

    For more information about product features, specifications, options, configurations, and compatibility, see the HPE DDR4 SmartMemory QuickSpecs on the Hewlett Packard Enterprise website (http://www.hpe.com/ support/DDR4SmartMemoryQS). DIMM slot locations The DIMM slots are numbered 1 through 6. The arrow in the following illustration points to the front of the server.

  • Page 17: Drives

    Item Description Definition Each PCIe version corresponds to a specific data PCI Express version transfer rate between the processor and peripheral devices. Generally, a version update corresponds to an increase in transfer rate. • PCIe 1.x • PCIe 2.x • PCIe 3.x The PCIe technology is under constant development.

  • Page 18: Hot-Plug Drive Led Definitions

    Item Status Definition Flashing amber/blue The drive has failed, or a predictive failure alert has been received for this drive; it also has been identified by a (1 flash per second) management application. Flashing amber A predictive failure alert has been received for this drive. Replace the drive as soon as possible.

  • Page 19: Drive Bay Numbering

    Item LED Status Definition Do not Solid white Do not remove the drive. Removing the drive causes one or more of remove the logical drives to fail. Removing the drive does not cause a logical drive to fail. Drive Solid green The drive is a member of one or more logical drives.
  • Page 20 • LFF drive numbering: Smart Array controller • SFF drive bay numbering: Smart Array controller Component identification...

  • Page 21: Fans

    Fans Fan locations Item Description Default system fan Default PCI fan The server also supports the Redundant fan option kit on page 81. Fan mode behavior • In nonredundant fan mode, a fan failure or a missing fan causes: Component identification...
  • Page 22 ◦ The system Health LED to flash amber. ◦ The operating system to orderly shutdown. • In redundant fan mode: ◦ A fan rotor failure will switch the system to nonredundant fan mode. This change is indicated by the Health LED flashing amber. The system continues to operate normally in this mode.

  • Page 23: Operations

    Operations This chapter describes the hardware operations carried out prior to and after installing or removing a hardware option, or performing a server maintenance or troubleshooting procedure. Before performing these hardware operations, review and observe the server warnings and cautions. Power up the server To power up the server, use one of the following methods: •...
  • Page 24 Prerequisites Before you perform this procedure, make sure that you have a T-15 Torx screwdriver available. Procedure 1. Power down the server on page 23. 2. Remove all power: a. Disconnect each power cord from the power source. b. Disconnect each power cord from the server. 3.

  • Page 25: Position The Tower Server For Hardware Configuration

    7. Place the server on a sturdy, level surface. Position the tower server for hardware configuration Procedure Place the server on a flat, level surface with the access panel facing up. Remove the access panel WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the internal system components to cool before touching them.

  • Page 26: Install The Access Panel

    CAUTION: To prevent damage to electrical components, properly ground the server before beginning any installation procedure. Improper grounding can cause electrostatic discharge. Procedure 1. Power down the server on page 23. 2. Remove all power: a. Disconnect each power cord from the power source. b.

  • Page 27: Remove The Front Bezel

    a. Place the access panel on the chassis, and slide it towards the front of the server. b. Tighten the thumbscrews. 2. If a Kensington security cable was removed, connect it to the rear panel. See the security cable documentation for instructions. 3.

  • Page 28: Install The Front Bezel

    a. Slide up the internal locker. b. Open the front bezel. c. Remove the front bezel. Install the front bezel Procedure 1. Install and close the front bezel. 2. Do one of the following: • Lock the internal locker. • Leave the internal locker in unlock position if you want to access the front panel any time without removing the access panel.

  • Page 29: Remove The Pci Air Baffle

    3. Install the access panel on page 26. 4. Do one of the following: • Server in rack mode: Install the server into the rack on page 53. • Server in tower mode: Return the server to an upright position. 5.

  • Page 30: Install The Pci Air Baffle

    Install the PCI air baffle CAUTION: For proper cooling do not operate the server without the access panel, baffles, expansion slot covers, or blanks installed. Procedure 1. Install the PCI air baffle. 2. Install the front bezel on page 28. 3.

  • Page 31: Install The System Air Baffle

    3. Disconnect all peripheral cables from the server. 4. Do one of the following: • Server in rack mode: Remove the server from the rack on page 23. • Server in tower mode: Position the tower server for hardware configuration on page 25. 5.
  • Page 32 2. Install the PCI air baffle on page 30 3. Install the front bezel on page 28. 4. Install the access panel on page 26. 5. Do one of the following: • Server in rack mode: Install the server into the rack on page 53. •...

  • Page 33: Setup

    HPE Installation Service provides basic installation of Hewlett Packard Enterprise branded equipment, software products, as well as HPE-supported products from other vendors that are sold by HPE or by HPE authorized resellers. The Installation Service is part of a suite of HPE deployment services that are designed to give users the peace of mind that comes from knowing that their HPE and HPE-supported products have been installed by an HPE specialist.

  • Page 34: Setting Up The Server

    Verify that your OS or virtualization software is supported: http://www.hpe.com/info/ossupport • Read the HPE UEFI requirements for ProLiant servers on the Hewlett Packard Enterprise website. If the UEFI requirements are not met, you might experience boot failures or other errors when installing the operating system.
  • Page 35 Verify the following: ◦ iLO is licensed to use the remote console feature. If iLO is not licensed, visit http://www.hpe.com/info/ilo. ◦ The iLO Management Port is connected to a secure network. b. Using a browser, navigate to the iLO web interface, and then log in.
  • Page 36 Set up the storage 7. Set up the storage. Do one of the following: • To configure the server to boot from a SAN, see the following guide in the HPE website (https:// www.hpe.com/info/boot-from-san-config-guide): HPE Boot from SAN Configuration Guide •...

  • Page 37: Operational Requirements

    Press F11 at boot screen to select the boot device. c. After the OS installed, update the drivers. Register the server 9. To experience quicker service and more efficient support, register the server at the HPE website: https://myenterpriselicense.hpe.com Operational requirements...

  • Page 38: Temperature Requirements

    Temperature requirements To ensure continued safe and reliable equipment operation, install or position the system in a well-ventilated, climate-controlled environment. The maximum recommended ambient operating temperature (TMRA) for most server products is 35°C (95°F). The temperature in the room where the rack is located must not exceed 35°C (95°F). CAUTION: To reduce the risk of damage to the equipment when installing third-party options: •...

  • Page 39: Rack Warnings And Cautions

    WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the internal system components to cool before touching them. WARNING: To reduce the risk of fire or burns after removing the energy pack: • Do not disassemble, crush, or puncture the energy pack. •...

  • Page 40: Electrostatic Discharge

    WARNING: The server is heavy. To reduce the risk of personal injury or damage to the equipment, do the following: • Observe local occupational health and safety requirements and guidelines for manual material handling. • Get help to lift and stabilize the product during installation or removal, especially when the product is not fastened to the rails.

  • Page 41: Setting Up The Server In Tower Mode

    To prevent electrostatic damage: • Avoid hand contact by transporting and storing products in static-safe containers. • Keep electrostatic-sensitive parts in their containers until they arrive at static-free workstations. • Place parts on a grounded surface before removing them from their containers. •...

  • Page 42: Installing Or Deploying An Operating System

    Before installing an operating system, observe the following: • Be sure to read the HPE UEFI requirements for ProLiant servers on the Hewlett Packard Enterprise website. If UEFI requirements are not met, you might experience boot failures or other errors when installing the operating system.

  • Page 43: Hardware Options Installation

    Hardware options installation This chapter provides detailed instructions on how to install hardware options. For more information on supported options, see the product QuickSpecs on the HPE ProLiant 110 Gen10 Server website at: http://www.hpe.com/servers/ml110-gen10 To view the warranty for your server and supported options, see Warranty information on page 133.

  • Page 44: Installing An Lff Non-Hot-Plug Drive

    Installing an LFF non-hot-plug drive Prerequisites Before you perform this procedure, make sure that you have a T-15 Torx screwdriver available. Procedure Power down the server on page 23. Remove all power: a. Disconnect each power cord from the power source. b.
  • Page 45 12. Install the 4 LFF non-hot-plug drive cage assembly. 13. Connect the drive cables. 14. Install the system air baffle on page 31. 15. Install the PCI air baffle on page 30. 16. Install the front bezel on page 28. 17.

  • Page 46: Installing An Lff Hot-Plug Drive

    21. Connect each power cord to the power source. 22. Power up the server on page 23. The installation is complete. To configure arrays, see the HPE Smart Array SR Gen10 Configuration Guide at the Hewlett Packard Enterprise website. Installing an LFF hot-plug drive CAUTION: To prevent improper cooling and thermal damage, do not operate the rack unless all device bays are populated with either a component or a blank.

  • Page 47: Installing An Sff Hot-Plug Drive

    6. Determine the status of the drive from the drive LED definitions. 7. Close the front bezel. The installation is complete. To configure arrays, see the HPE Smart Array SR Gen10 Configuration Guide at the Hewlett Packard Enterprise website. Installing an SFF hot-plug drive CAUTION: To prevent improper cooling and thermal damage, do not operate the rack unless all device bays are populated with either a component or a blank.

  • Page 48: Tower-To-Rack Conversion Kit

    6. Determine the status of the drive from the drive LED definitions. 7. Close the front bezel. The installation is complete. To configure arrays, see the HPE Smart Array SR Gen10 Configuration Guide at the Hewlett Packard Enterprise website. Tower-to-rack conversion kit Use the tower-to-rack conversion kit to switch the tower server to rack mode operation.

  • Page 49: Installing The Tower-To-Rack Conversion Kit

    • M5 square-hole cage nuts (4) • Rear shipping screws (2) Installing the tower-to-rack conversion kit Use the tower-to-rack conversion kit to switch the tower server to rack mode operation. After the kit is installed, complete in-rack serviceability for all server components is supported. Procedure 1.

  • Page 50: Install The Rack Rails And Server Tray

    Install the rack rails and server tray These rack rails can be installed in both round- or square-hole racks. Prerequisites Before you perform this procedure, make sure that you have the following items available: • Left and right rack rail assemblies – These rails occupy 1U position on the rack. •...
  • Page 51 c. Repeat steps a–b on the other rail assembly. 2. Install the sliding rails on the server tray: a. Align the notches on the rail with the pins on the side. b. Slide the rail towards the rear of the tray to lock it into place. c.
  • Page 52 4. Fasten the mounting rails to the rack columns: a. Retract and hold the rear retention bracket. b. Insert the pegs on the mounting flange into the rack holes. c. Release the rear retention bracket. d. Retract and hold the front retention bracket. e.

  • Page 53: Install The Server Into The Rack

    g. Repeat steps a-f to fasten the other mounting rail. h. Make sure that both rails are mounted at the same vertical position on both sides of the rack. 5. Slide the server tray into the rack. The rails will click and lock into place when the tray is properly engaged. Install the server into the rack Prerequisites Before you perform this procedure, make sure that you have a T-15 Torx screwdriver available.
  • Page 54 2. Place the server at the center of the server tray. Align the front panel of the server with the edge of the tray. 3. Press and hold the blue rail-release tabs, and then slide the server tray back into the rack. Hardware options installation...
  • Page 55 4. Tighten the server tray thumbscrews. 5. Connect all peripheral cables and power cords to the rear panel. 6. Secure the power cord with the strain relief strap. Roll the extra length of the strap around the power input module handle. Hardware options installation...

  • Page 56: Enable The Increased Cooling Function

    Hot-plug power supply calculations For more information on the hot-plug power supply and calculators to determine server power consumption in various system configurations, see the Hewlett Packard Enterprise Power Advisor website (http:// www.hpe.com/info/poweradvisor/online). Hardware options installation...

  • Page 57: Power Supply Warnings And Cautions

    Power supply warnings and cautions WARNING: To reduce the risk of electric shock or damage to the equipment: • Do not disable the power cord grounding plug. The grounding plug is an important safety feature. • Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all times. •...
  • Page 58 • Server in rack mode: Remove the server from the rack on page 23. • Server in tower mode: Position the tower server for hardware configuration on page 25. Remove the access panel on page 25. Remove the PCI air baffle on page 29. Remove the system air baffle on page 30.

  • Page 59: Redundant Power Supply Enablement Option

    14. Install the access panel on page 26. 15. Do one of the following: • Server in rack mode: Install the server into the rack on page 53. • Server in tower mode: Return the server to an upright position. 16.
  • Page 60 Remove the PCI air baffle on page 29. Remove the system air baffle on page 30. Disconnect all power supply cables from the system board, drive cages, and devices. Remove the non-hot-plug power supply. 10. Install the RPS bracket. 11. Install the RPS backplane. Hardware options installation...
  • Page 61 12. Connect the RPS backplane cables. 13. Install a hot-plug power supply in the power supply bay 1. When facing the rear of the server in an upright position, the upper level of power supply bay is bay 1 and the lower level is bay 2. 14.
  • Page 62 b. Install a second hot-plug power supply in the power supply bay 2. 15. Connect each power cord to the server. 16. Secure the power cord in the strain relief strap attached to the power supply handle: a. Unwrap the strain relief strap from the power supply handle. CAUTION: Avoid tight bend radii to prevent damaging the internal wires of a power cord or a server cable.

  • Page 63: Drive Cage Options

    20. Do one of the following: • Server in rack mode: Install the server into the rack on page 53. • Server in tower mode: Return the server to an upright position. 21. Connect all peripheral cables to the server. 22.
  • Page 64 Remove the front bezel on page 27. Remove the PCI air baffle on page 29. Remove the system air baffle on page 30. Remove the drive bay cover from box 2. 10. Install the non-hot-plug drives. 11. Install the drive cage in box 2. 12.

  • Page 65: Installing The Four-Bay Lff Hot-Plug Drive Cage

    • Server in rack mode: Install the server into the rack on page 53. • Server in tower mode: Return the server to an upright position. 18. Connect all peripheral cables to the server. 19. Connect each power cord to the server. 20.
  • Page 66 11. Install the drive cage in box 1. 12. Connect the drive cables. 13. Install the LFF hot-plug drives. 14. Install the system air baffle on page 31. 15. Install the PCI air baffle on page 30. 16. Install the front bezel on page 28. 17.

  • Page 67: Installing The Eight-Bay Sff Hot-Plug Drive Cage

    20. Connect each power cord to the server. 21. Connect each power cord to the power source. 22. Power up the server on page 23. The installation is complete. Installing the eight-bay SFF hot-plug drive cage The eight-bay SFF hot-plug drive cage can be installed in both box 1 and box 2. Prerequisites Before you perform this procedure, make sure that you have the following items available: •...
  • Page 68 11. Install the drive cage in box 1. 12. Connect the drive cables. 13. Install the SFF hot-plug drives. 14. Install the system air baffle on page 31. 15. Install the PCI air baffle on page 30. 16. Install the front bezel on page 28. 17.

  • Page 69: Installing The Optical Drive Option

    20. Connect each power cord to the server. 21. Connect each power cord to the power source. 22. Power up the server on page 23. The installation is complete. Installing the optical drive option Procedure Power down the server on page 23. Remove all power: a.
  • Page 70 10. Connect the cable to the rear of the drive and then route the cable through the drive bay. 11. Connect the optical drive SATA and power cable to the system board and power supply. 12. Install the system air baffle on page 31. 13.

  • Page 71: Storage Controller Options

    Storage controller options The server supports the following storage controllers: • For SATA drives only – Embedded HPE Smart Array S100i SR Gen10 Controller • For SAS and SATA drives – Smart Array type-p SR Gen10 controllers For the location and description of the PCIe3 expansion slots, see System board components on page For more information on PCIe slot descriptions, see PCIe slot description on page 16.
  • Page 72 • If the new Smart Array is the new boot device, install the device drivers. • If the new Smart Array is not the new boot device, go to the next step. 5. Ensure that users are logged off and that all tasks are completed on the server. CAUTION: In systems that use external data storage, be sure that the server is the first unit to be powered down and the last to be powered back up.

  • Page 73: Configuring An Hpe Smart Array Gen10 Controller

    11. Make sure that the controller board is firmly seated in the slot. 12. Cable the controller. 13. To enable HPE Smart Array SR SmartCache in a Smart Array P-class type-p Gen10 controller, connect the storage controller backup power cable.

  • Page 74: Energy Pack Options

    6. If the new controller is not the new boot device, install the device drivers. 7. If the controller firmware is not the latest version, use SPP to update it. 8. Use UEFI System Utilities or HPE Smart Storage Administrator (HPE SSA) to create arrays and logical drives.

  • Page 75: Hpe Smart Storage Hybrid Capacitor

    Storage controller backup power cable (ships with the controller) ◦ Energy pack option • If you are installing the HPE Smart Storage Hybrid Capacitor, verify that the system BIOS meets the minimum firmware requirements. Procedure Back up all server data.
  • Page 76 • Server in rack mode: Remove the server from the rack on page 23. • Server in tower mode: Position the tower server for hardware configuration on page 25. Remove the access panel on page 25. Remove the PCI air baffle on page 29. Remove the system air baffle on page 30.

  • Page 77: Expansion Board Options

    12. Connect the storage controller backup power cable. 13. Install the system air baffle on page 31. 14. Install the PCI air baffle on page 30. 15. Install the access panel on page 26. 16. Do one of the following: •...
  • Page 78 • Expansion board option kit • Internal and external cabling required by the expansion board • T-15 Torx screwdriver Procedure Back up all server data. Power down the server on page 23. Remove all power: a. Disconnect each power cord from the power source. b.

  • Page 79: Installing The Gpu Option

    For specific information about power requirements of a GPU, see the GPU user documentation. For a list of specific GPU models supported, see the product QuickSpecs on the server product page at http://www.hpe.com/servers/ml110-gen10. Prerequisites Before installing this option, make sure that you have the following items available: •...
  • Page 80 Procedure Back up all server data. Power down the server on page 23. Remove all power: a. Disconnect each power cord from the power source. b. Disconnect each power cord from the server. Disconnect all peripheral cables from the server. Do one of the following: •...

  • Page 81: Redundant Fan Option Kit

    11. Make sure that the GPU is firmly seated in the slot. 12. Close the PCIe slot cover retainer. 13. Install the system air baffle on page 31. 14. Install the PCI air baffle on page 30. 15. Install the access panel on page 26. 16.

  • Page 82: Installing The Redundant Fans

    Installing the redundant fans Prerequisites Before you perform this procedure, make sure that: • The redundant power supply is installed. • You have a T-15 Torx screwdriver available. Procedure Power down the server on page 23. Remove all power: a. Disconnect each power cord from the power source. b.
  • Page 83 a. Insert the fan guard pins into the front chassis openings. b. Tighten the four T-15 screws. 11. Connect the redundant PCI fan cables. 12. Remove the default system fan. 13. Install the redundant system fan: a. Insert the fan guard pins into the rear chassis openings. b.

  • Page 84: Memory Options

    DIMM population information For specific DIMM population information, see the DIMM population guidelines on the Hewlett Packard Enterprise website (http://www.hpe.com/docs/memory-population-rules). DIMM-processor compatibility The installed processor determines the type of DIMM that is supported in the server:...

  • Page 85: Hpe Smartmemory Speed Information

    Second-generation Intel Xeon Scalable processors support DDR4-2933 DIMMs. Mixing DIMM types is not supported. Install only the supported DDR4-2666 or DDR4-2933 DIMMs in the server. HPE SmartMemory speed information For more information about memory speed information, see the Hewlett Packard Enterprise website (https:// www.hpe.com/docs/memory-speed-table).

  • Page 86: M.2 Ssd Enablement Option

    The DIMM slots are structured to ensure proper installation. If you try to insert a DIMM but it does not fit easily into the slot, you might have positioned it incorrectly. Reverse the orientation of the DIMM and insert it again. Install the system air baffle on page 31.
  • Page 87 • M.2 SSD enablement option • M.2 SSD • T-15 Torx screwdriver • Phillips No.1 screwdriver Procedure Power down the server on page 23. Remove all power: a. Disconnect each power cord from the power source. b. Disconnect each power cord from the server. Disconnect all peripheral cables from the server.
  • Page 88 d. If you are installing a second SSD, repeat steps a–b. Open the PCIe slot cover retainer and remove a slot blank. 10. Locate the appropriate PCIe slot to install the M.2 SSD enablement board. The recommended slots are 1, 3, and 4. 11.

  • Page 89: Internal Usb Device Option

    21. Connect each power cord to the power source. 22. Power up the server on page 23. The installation is complete. To configure the M.2 SATA SSDs, see the HPE Smart Array SR Gen10 Configuration Guide at the Hewlett Packard Enterprise website. Internal USB device option The server has one internal USB 2.0 port and one USB 3.0 port.

  • Page 90: Installing An Internal Usb Device

    Installing an internal USB device Procedure Power down the server on page 23. Remove all power: a. Disconnect each power cord from the power source. b. Disconnect each power cord from the server. Disconnect all peripheral cables from the server. Do one of the following: •...

  • Page 91: Installing The Serial Port Option

    14. Connect all peripheral cables to the server. 15. Connect each power cord to the server. 16. Connect each power cord to the power source. 17. Power up the server on page 23. The installation is complete. Installing the serial port option Prerequisites Before you perform this procedure, make sure that you have the following items available: •...
  • Page 92 Install the serial port: a. Slide the serial port bracket into the fourth slot blank opening. b. Secure the serial port bracket with the T-15 screw. 10. Close the PCIe slot cover retainer. 11. Connect the serial port cable. 12. Install the system air baffle on page 31. 13.

  • Page 93: Hpe Trusted Platform Module 2.0 Gen10 Option

    HPE Trusted Platform Module 2.0 Gen10 option Overview Use these instructions to install and enable an HPE TPM 2.0 Gen10 Kit in a supported server. This option is not supported on Gen9 and earlier servers. This procedure includes three sections: 1.

  • Page 94: Installing And Enabling The Hpe Tpm 2.0 Gen10 Kit

    Hewlett Packard Enterprise is not liable for blocked data access caused by improper TPM use. For operating instructions, see the TPM documentation or the encryption technology feature documentation provided by the operating system. Installing and enabling the HPE TPM 2.0 Gen10 Kit Installing the Trusted Platform Module board Preparing the server for installation...
  • Page 95 Power down the server (Power down the server on page 23). Remove all power: a. Disconnect each power cord from the power source. b. Disconnect each power cord from the server. Disconnect all peripheral cables from the server. Do one of the following: •...
  • Page 96 3. Install the TPM cover: a. Line up the tabs on the cover with the openings on either side of the TPM connector. b. To snap the cover into place, firmly press straight down on the middle of the cover. 4.

  • Page 97: Enabling The Trusted Platform Module

    • Server in rack mode: Install the server into the rack on page 53. • Server in tower mode: Return the server to an upright position. 5. Connect all peripheral cables to the server. 6. Connect each power cord to the server. 7.

  • Page 98: Retaining The Recovery Key/Password

    • Changing from TPM 1.2 and TPM 2.0 • Changing TPM bus from FIFO to CRB • Enabling or disabling TPM • Clearing the TPM 8. Enable TPM functionality in the OS, such as Microsoft Windows BitLocker or measured boot. For more information, see the Microsoft website.

  • Page 99: Cabling

    Cabling Cabling guidelines The cable colors in the cabling diagrams used in this chapter are for illustration purposes only. Most of the server cables are black. Observe the following guidelines when working with server cables. Before connecting cables • Note the port labels on the PCA components. Not all of these components are used by all servers: ◦...

  • Page 100: Drive Cabling

    • Remove cables that are no longer being used. Retaining them inside the server can restrict airflow. If you intend to use the removed cables later, label and store them for future use. Drive cabling LFF non-hot-plug drive cabling Eight bay LFF non-hot-plug drive cabling Cable Color Description Orange...

  • Page 101: Lff Hot-Plug Drive Cabling

    Cable Color Description Green Box 2 drive power supply cable Blue Box 1 drive power supply cable Black Box 2 non-hot-plug drive to system board x4 SATA port 2 Gold Box 1 non-hot-plug drive to system board x4 SATA port 1 LFF hot-plug drive cabling Box 1 drive backplane connected to the system board Cable Color...
  • Page 102 Box 2 drive backplane connected the system board Cable Color Description Orange Drive power supply cable Blue Box 2 drive backplane Mini-SAS cable to system board x4 SATA port 2 Box 1 and Box 2 drive backplanes connected to a Smart Array controller Cable Color Description Orange...

  • Page 103: Sff Hot-Plug Drive Cabling

    Cable Color Description Gold Box 2 drive backplane Mini-SAS cable to controller port 2 Pink Box 1 drive backplane Mini-SAS cable to controller port 1 SFF hot-plug drive cabling Box 1 drive backplane connected to the system board Cable color Description Orange Drive power supply cable...

  • Page 104: Storage Controller Cabling

    Box 1 drive backplane connected to a Smart Array controller Cable color Description Orange Drive power supply cable Blue Box 1 drive backplane port 1 Mini-SAS cable to type-p controller port 1 Gold Box 1 drive backplane port 2 Mini-SAS cable to type-p controller port 2 Storage controller cabling Smart Array controller connected to the two 4-bay LFF hot-plug drive cage Cabling...
  • Page 105 Cable color Description Orange Box 1 drive backplane Mini-SAS cable to type-p controller port 1 Blue Box 2 drive backplane Mini-SAS cable to type-p controller port 2 Gold Box 1 drive power supply cable Pink Box 2 drive power supply cable Smart Array controllers connected to the 16-bay SFF hot-plug drive cage Cable color Description...

  • Page 106: Storage Controller Backup Power Cabling

    Storage controller backup power cabling Energy pack cabling Cabling...

  • Page 107: Optical Drive Cabling

    Optical drive cabling Cable color Description Orange Power supply cable Blue Drive power supply cable Gold SATA cable M.2 SSD cabling Cabling...

  • Page 108: Front I/O Cabling

    Cable Color Description Orange SATA cable from M.2 SSD enablement board port 1 to system board SATA port 9 Blue SATA cable from M.2 SSD enablement board port 2 to system board SATA port 10 Front I/O cabling Front USB 3.0 cabling Cabling...

  • Page 109: Ilo Service Port Cabling

    iLO Service Port cabling Fan cabling Default system fan cabling Cabling...
  • Page 110 Redundant system fan cabling Cable color Description Orange System fan cable to fan connector 4 Blue System fan cable to fan connector 3 Default PCI fan cabling Cabling...

  • Page 111: Serial Port Cabling

    Redundant PCI fan cabling Cable color Description Orange PCI fan cable to fan connector 1 Blue PCI fan cable to fan connector 2 Serial port cabling Cabling...

  • Page 112: Power Supply Cabling

    Power supply cabling ATX 350W non-hot-plug power supply Cable Color Description Orange 8-pin power supply cable to box 2 drive backplane Blue 8-pin power supply cable to box 1 drive backplane and optical drive Gold 4-pin power supply cable to system board Pink 24-pin power supply cable ATX 550W non-hot-plug power supply...
  • Page 113 Cable Color Description Orange 8-pin power supply cable to box 2 drive backplane and optical drive Blue 8-pin power supply cable to box 1 drive backplane Gold 4-pin power supply cable to system board Pink 24-pin power supply cable Flexible slot power supply (hot-plug) Cable Color Description Pink...

  • Page 114: Software And Configuration Utilities

    Product QuickSpecs For more information about product features, specifications, options, configurations, and compatibility, see the product QuickSpecs on the Hewlett Packard Enterprise website (http://www.hpe.com/info/qs). Active Health System Viewer Active Health System Viewer (AHSV) is an online tool used to read, diagnose, and resolve server issues quickly using AHS uploaded data.

  • Page 115: Active Health System Data Collection

    HPE iLO 5 iLO 5 is a remote server management processor embedded on the system boards of HPE ProLiant servers and Synergy compute modules. iLO enables the monitoring and controlling of servers from remote locations.

  • Page 116: Ilo Federation

    Service Port To find out if your server model supports this feature, see the server specifications document at the following website: http://www.hpe.com/info/qs. When you have physical access to a server, you can use the Service Port to do the following: Download the Active Health System Log to a supported USB flash drive.

  • Page 117: Ilo Restful Api

    Intelligent Provisioning 3.30 and later includes HPE SMB Setup. When you launch F10 mode from the POST screen, you are prompted to select whether you want to enter the Intelligent Provisioning or HPE SMB Setup mode. NOTE: After you have selected a mode, you must reprovision the server to change the mode that launches when you boot to F10.

  • Page 118: Intelligent Provisioning Operation

    To access Intelligent Provisioning: • Press F10 from the POST screen and enter either Intelligent Provisioning or HPE SMB Setup. • From the iLO web interface using Always On. Always On allows you to access Intelligent Provisioning without rebooting your server.

  • Page 119: Management Security

    Management Security HPE ProLiant Gen10 servers are built with some of the industry's most advanced security capabilities, out of the box, with a foundation of secure embedded management applications and firmware. The management security provided by HPE embedded management products enables secure support of modern workloads, protecting your components from unauthorized access and unapproved use.

  • Page 120: Selecting The Boot Mode

    • An Embedded UEFI Shell that provides a preboot environment for running scripts and tools. • Boot support for option cards that only support a UEFI option ROM. Selecting the boot mode This server provides two Boot Mode configurations: UEFI Mode and Legacy BIOS Mode. Certain boot options require that you select a specific boot mode.

  • Page 121: Launching The Embedded Uefi Shell

    HPE Smart Storage Administrator HPE SSA is the main tool for configuring arrays on HPE Smart Array SR controllers. It exists in three interface formats: the HPE SSA GUI, the HPE SSA CLI, and HPE SSA Scripting. All formats provide support for configuration tasks.

  • Page 122: Hpe Infosight For Servers

    For more information, see HPE Smart Array SR Gen10 Configuration Guide at the Hewlett Packard Enterprise website. HPE InfoSight for servers The HPE InfoSight portal is a secure web interface hosted by HPE that allows you to monitor supported devices through a graphical interface. HPE InfoSight for servers: •...

  • Page 123: Redundant Rom Support

    SPP is a systems software and firmware solution delivered as a single ISO file download. This solution uses SUM as the deployment tool and is tested and supports HPE ProLiant, HPE BladeSystem, HPE Synergy, and HPE Apollo servers and infrastructure.

  • Page 124: Updating Firmware From The System Utilities

    NOTE: SUM does not support third-party controllers, including flashing hard drives behind the controllers. Integrated Smart Update Tools Integrated Smart Update Tools (iSUT) is a software utility used with iLO 4, iLO 5, iLO Amplifier Pack, HPE OneView, Service Pack for ProLiant (SPP), and Smart Update Manager (SUM) to stage, install, and activate firmware and driver updates.

  • Page 125: Updating The Firmware From The Uefi Embedded Shell

    Procedure 1. Access the System ROM Flash Binary component for your server from the Hewlett Packard Enterprise Support Center (http://www.hpe.com/support/hpesc). 2. Copy the binary file to a USB media or iLO virtual media. 3. Attach the media to the server.

  • Page 126: Drivers

    HPE Pointnext Portfolio HPE Pointnext delivers confidence, reduces risk, and helps customers realize agility and stability. Hewlett Packard Enterprise helps customers succeed through Hybrid IT by simplifying and enriching the on-premise experience, informed by public cloud qualities and attributes.

  • Page 127: Proactive Notifications

    Proactive notifications 30 to 60 days in advance, Hewlett Packard Enterprise sends notifications to subscribed customers on upcoming: • Hardware, firmware, and software changes • Bulletins • Patches • Security alerts You can subscribe to proactive notifications on the Hewlett Packard Enterprise website. Software and configuration utilities...

  • Page 128: System Battery Replacement

    System battery replacement System battery information The server contains an internal lithium manganese dioxide, a vanadium pentoxide, or an alkaline battery that provides power to the real-time clock. If this battery is not properly handled, a risk of the fire and burns exists. To reduce the risk of personal injury: •...

  • Page 129: Replace The System Battery

    14. Connect each power cord to the server. 15. Connect each power cord to the power source. 16. Power up the server on page 23. Replace the system battery Prerequisites Before you perform this procedure make sure you have a small flat-bladed, nonconductive tool available. Procedure 1.
  • Page 130 For more information about battery replacement or proper disposal, contact an authorized reseller or an authorized service provider. System battery replacement...

  • Page 131: Troubleshooting

    • Error Message Guide for HPE ProLiant Gen10 servers and HPE Synergy provides a list of error messages and information to assist with interpreting and resolving error messages. •...

  • Page 132: Safety, Warranty, And Regulatory Information

    To view the regulatory information for your product, view the Safety and Compliance Information for Server, Storage, Power, Networking, and Rack Products, available at the Hewlett Packard Enterprise Support Center: www.hpe.com/support/Safety-Compliance-EnterpriseProducts Additional regulatory information Hewlett Packard Enterprise is committed to providing our customers with information about the chemical substances in our products as needed to comply with legal requirements such as REACH (Regulation EC No 1907/2006 of the European Parliament and the Council).

  • Page 133: Turkey Rohs Material Content Declaration

    Фараби даңғ ылы, 77/7, Телефон/факс: +7 727 355 35 50 Manufacturing date: The manufacturing date is defined by the serial number. If you need help identifying the manufacturing date, contact tre@hpe.com. Turkey RoHS material content declaration Türkiye Cumhuriyeti: AEEE Yönetmeliğine Uygundur...

  • Page 134: Specifications

    175 m (1.8°F per every 574 ft) above 900 m (2953 ft) to a maximum of 3050 m (10,000 ft) • Redundant fans are required when the ambient temperature reaches 35°C (95°F) to 40°C (104°F). The approved hardware configurations for this system are listed on the Hewlett Packard Enterprise website (http://www.hpe.com/servers/ASHRAE). Mechanical specifications Dimension (with feet/bezel) Value Height 44.00 cm (17.32 in)

  • Page 135: Power Supply Specifications

    ATX 550W non-hot-plug power supply on page 135 • HPE 800W Flex Slot Platinum Hot-plug Low Halogen Power Supply on page 136 CAUTION: Check the system and power supply input ratings before powering up the server. ATX 350W non-hot-plug power supply...

  • Page 136: Hpe 800W Flex Slot Platinum Hot-Plug Low Halogen Power Supply

    1876 at 240 VAC Power supply output Rated steady-state power 550 W at 100VAC to 240VAC Maximum peak power 575 W at 100VAC to 240VAC HPE 800W Flex Slot Platinum Hot-plug Low Halogen Power Supply Specification Value Input requirements — Rated input voltage...
  • Page 137 Specification Value Rated steady-state power 800 W at 100 VAC to 127 VAC input 800 W at 100 VAC to 240 VAC input 800 W at 240 VDC input for China only Maximum peak power 800 W at 100 VAC to 127 VAC input 800 W at 100 VAC to 240 VAC input 800 W at 240 VDC input for China only Specifications...

  • Page 138: Websites

    Storage white papers and analyst reports www.hpe.com/storage/whitepapers For additional general support websites, see Support and other resources on page 139. Product websites Product QuickSpecs http://www.hpe.com/servers/ml110-gen10 HPE ProLiant ML110 Gen10 support page http://www.hpe.com/support/ml110gen10 HPE ProLiant ML110 Gen10 documents http://www.hpe.com/info/ml110gen10-docs Websites...

  • Page 139: Support And Other Resources

    Support and other resources Accessing Hewlett Packard Enterprise Support • For live assistance, go to the Contact Hewlett Packard Enterprise Worldwide website: http://www.hpe.com/info/assistance • To access documentation and support services, go to the Hewlett Packard Enterprise Support Center website: http://www.hpe.com/support/hpesc Information to collect •...

  • Page 140: Customer Self Repair

    Hewlett Packard Enterprise Support Center More Information on Access to Support Materials page: www.hpe.com/support/AccessToSupportMaterials IMPORTANT: Access to some updates might require product entitlement when accessed through the Hewlett Packard Enterprise Support Center. You must have an HPE Passport set up with relevant entitlements. Customer self repair Hewlett Packard Enterprise customer self repair (CSR) programs allow you to repair your product.

  • Page 141: Documentation Feedback

    Documentation Feedback (docsfeedback@hpe.com). When submitting your feedback, include the document title, part number, edition, and publication date located on the front cover of the document. For online help content, include the product name, product version, help edition, and publication date located on the legal notices page.

  • Page 142: Acronyms And Abbreviations

    American Society of Heating, Refrigerating and Air-Conditioning Engineers column address strobe Canadian Standards Association customer self repair DDR4 double data rate-4 graphics processing unit HPE SSA HPE Smart Storage Administrator International Electrotechnical Commission Integrated Lights-Out Integrated Management Log International Organization for Standardization Acronyms and abbreviations...
  • Page 143 iSUT Integrated Smart Update Tools large form factor LRDIMM load reduced dual in-line memory module nonmaskable interrupt printed circuit assembly PCIe Peripheral Component Interconnect Express power distribution unit POST Power-On Self-Test Preboot eXecution Environment Reliability, Accessibility, Serviceability RBSU ROM-Based Setup Utility RDIMM registered dual in-line memory module REST...
  • Page 144 small form factor scripting toolkit StorCLI Storage Command Line Interface Service Pack for ProLiant solid state drive Smart Update Manager TMRA recommended ambient operating temperature Trusted Platform Module UDIMM unregistered dual in-line memory module UEFI Unified Extensible Firmware Interface unit identification Acronyms and abbreviations...

Table of Contents
