HPE ProLiant ML110 Gen9 Server
Maintenance and Service Guide
Abstract
This guide describes identification and maintenance procedures, diagnostic tools, specifications and requirements for hardware
components and software. This guide is for an experienced service technician. Hewlett Packard Enterprise assumes that you are
qualified in the servicing of computer equipment, trained in recognizing hazards in products, and are familiar with weight and stability
precautions.
Part Number: 790389-006
August 2017
Edition: 6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProLiant ML110 Gen9 and is the answer not in the manual?

Questions and answers

Related Manuals for HPE ProLiant ML110 Gen9

Summary of Contents for HPE ProLiant ML110 Gen9

  • Page 1 HPE ProLiant ML110 Gen9 Server Maintenance and Service Guide Abstract This guide describes identification and maintenance procedures, diagnostic tools, specifications and requirements for hardware components and software. This guide is for an experienced service technician. Hewlett Packard Enterprise assumes that you are qualified in the servicing of computer equipment, trained in recognizing hazards in products, and are familiar with weight and stability precautions.
  • Page 2 © Copyright 2015, 2016 Hewlett Packard Enterprise Development LP The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.

  • Page 3: Table Of Contents

    System battery ............................... 58 Dedicated iLO port management module ....................... 59 Enabling the dedicated iLO management module ..................60 HPE ATX 350-W Power Supply (non-hot-plug) ...................... 61 HPE ATX 550-W Power Supply (non-hot-plug) ...................... 61 RPS enablement kit ..............................62 HPE redundant power supply input module ......................
  • Page 4 GPU cabling ................................93 Fan cabling ................................94 Power supply cabling ............................. 95 HPE ATX 350 W power supply (non-hot-plug) .................... 95 HPE ATX 550 W power supply (non-hot-plug) .................... 96 HPE 750 W redundant power supply ......................96 Front I/O cabling ..............................97 Front USB 3.0 cabling ............................

  • Page 5: Customer Self Repair

    For more information about the Hewlett Packard Enterprise CSR program, contact your local service provider. For the North American program, go to the Hewlett Packard Enterprise CSR website (http://www.hpe.com/support/selfrepair). Parts only warranty service Your Hewlett Packard Enterprise Limited Warranty may include a parts only warranty service. Under the terms of parts only warranty service, Hewlett Packard Enterprise will provide replacement parts free of charge.
  • Page 6 Pour plus d'informations sur le programme CSR de Hewlett Packard Enterprise, contactez votre Mainteneur Agrée local. Pour plus d'informations sur ce programme en Amérique du Nord, consultez le site Web Hewlett Packard Enterprise (http://www.hpe.com/support/selfrepair). Service de garantie "pièces seules" Votre garantie limitée Hewlett Packard Enterprise peut inclure un service de garantie "pièces seules".
  • Page 7 Per ulteriori informazioni sul programma CSR di Hewlett Packard Enterprise, contattare il centro di assistenza di zona. Per il programma in Nord America fare riferimento al sito Web (http://www.hpe.com/support/selfrepair). Servizio di garanzia per i soli componenti La garanzia limitata Hewlett Packard Enterprise può includere un servizio di garanzia per i soli componenti.
  • Page 8 Weitere Informationen über das Hewlett Packard Enterprise Customer Self Repair Programm erhalten Sie von Ihrem Servicepartner vor Ort. Informationen über das CSR-Programm in Nordamerika finden Sie auf der Hewlett Packard Enterprise Website unter (http://www.hpe.com/support/selfrepair). Parts-only Warranty Service (Garantieservice ausschließlich für Teile) Ihre Hewlett Packard Enterprise Garantie umfasst möglicherweise einen Parts-only Warranty Service...
  • Page 9 Packard Enterprise, póngase en contacto con su proveedor de servicios local. Si está interesado en el programa para Norteamérica, visite la página web de Hewlett Packard Enterprise CSR (http://www.hpe.com/support/selfrepair). Servicio de garantía exclusivo de componentes La garantía limitada de Hewlett Packard Enterprise puede que incluya un servicio de garantía exclusivo de componentes.
  • Page 10 Neem contact op met een Service Partner voor meer informatie over het Customer Self Repair programma van Hewlett Packard Enterprise. Informatie over Service Partners vindt u op de Hewlett Packard Enterprise website (http://www.hpe.com/support/selfrepair). Garantieservice "Parts Only" Het is mogelijk dat de Hewlett Packard Enterprise garantie alleen de garantieservice "Parts Only"...
  • Page 11 Para obter mais informações sobre o programa de reparo feito pelo cliente da Hewlett Packard Enterprise, entre em contato com o fornecedor de serviços local. Para o programa norte-americano, visite o site da Hewlett Packard Enterprise (http://www.hpe.com/support/selfrepair). Serviço de garantia apenas para peças A garantia limitada da Hewlett Packard Enterprise pode incluir um serviço de garantia apenas para...
  • Page 12 Customer self repair 12...
  • Page 13 Customer self repair 13...
  • Page 14 Customer self repair 14...

  • Page 15: Illustrated Parts Catalog

    Illustrated parts catalog Mechanical components Hewlett Packard Enterprise continually improves and changes product parts. For complete and current supported parts information, see the Hewlett Packard Enterprise PartSurfer website (http://www.hpe.com/info/partssurfer). Item Description Spare part number Customer self repair (on page 5)
  • Page 16 Facultatif—Pièces pour lesquelles une réparation par le client est facultative. Ces pièces sont également conçues pour que le client puisse procéder lui-même aux réparations. Cependant, les frais supplémentaires engendrés par le remplacement de ces pièces par Hewlett Packard Enterprise dépendent du type de service de garantie désigné pour votre produit.

  • Page 17: System Components

    System components Hewlett Packard Enterprise continually improves and changes product parts. For complete and current supported parts information, see the Hewlett Packard Enterprise PartSurfer website (http://www.hpe.com/info/partssurfer). Illustrated parts catalog 17...
  • Page 18 791708-001 Mandatory HPE ATX 350-W Power Supply (non-hot-plug) 791705-001 Mandatory HPE ATX 550-W Power Supply (non-hot-plug) 791706-001 Mandatory HPE 750-W Common Slot Gold Hot Plug Power Supply 511778-001 Mandatory RPS enablement kit 791712-001 Optional Optional 4-bay LFF hot-plug drive cage...
  • Page 19 Mandatory a) 8 GB, single-rank x4 PC4-2400T-R* 819410-001 b) 8 GB, single-rank x8 PC4-2400T-R* 852545-001 Mandatory c) 16 GB, single-rank x4 PC4-2400T-R* 819411-001 Mandatory d) 16 GB, dual-rank x4 PC4-2400T-R* 846740-001 Mandatory e) 32 GB, dual-rank x4 PC4-2400T-R* 819412-001 Mandatory System battery 234556-001 Mandatory...
  • Page 20 812119-001 *Not shown **All processors in this HPE ProLiant server must have the same cache size, speed, number of cores, and rated maximum power consumption. Mandatory—Parts for which customer self repair is mandatory. If you request Hewlett Packard Enterprise to replace these parts, you will be charged for the travel and labor costs of this service.
  • Page 21 Obligatorio—Componentes cuya reparación por parte del usuario es obligatoria. Si solicita a Hewlett Packard Enterprise que realice la sustitución de estos componentes, tendrá que hacerse cargo de los gastos de desplazamiento y de mano de obra de dicho servicio. Opcional—Componentes cuya reparación por parte del usuario es opcional. Estos componentes también están diseñados para que puedan ser reparados por el usuario.

  • Page 22: Removal And Replacement Procedures

    Required tools You need the following items for some procedures: • T-10/T-15 Torx screwdriver (included with the server) • HPE Insight Diagnostics software ("Insight Diagnostics" on page 71) Safety considerations Before performing service procedures, review all the safety information. Preventing electrostatic discharge To prevent damaging the system, be aware of the precautions you must follow when setting up the system or handling parts.

  • Page 23: Server Warnings And Cautions

    This symbol indicates the presence of a hot surface or hot component. If this surface is contacted, the potential for injury exists. WARNING: To reduce the risk of injury from a hot component, allow the surface to cool before touching. This symbol indicates that the component exceeds the recommended weight for one individual to handle safely.

  • Page 24: Power Down The Server

    • Remove the PCI air baffle (on page 25). • Remove the system air baffle (on page 26). Power down the server Before powering down the server for any upgrade or maintenance procedures, perform a backup of critical server data and programs. IMPORTANT: When the server is in standby mode, auxiliary power is still being provided to the system.

  • Page 25: Remove The Front Bezel

    Slide and remove the access panel from the server. Remove the front bezel Power down the server (on page 24). Remove all power: Disconnect each power cord from the power source. Disconnect each power cord from the server. Place the server on its side. Remove the access panel (on page 24).

  • Page 26: Remove The System Air Baffle

    Disconnect each power cord from the power source. Disconnect each power cord from the server. Place the server on its side. Remove the access panel (on page 24). Remove the PCI air baffle. Remove the system air baffle Power down the server (on page 24). Remove all power: Disconnect each power cord from the power source.

  • Page 27: Non-Hot-Plug Drive Cage

    Remove the system air baffle. Non-hot-plug drive cage CAUTION: To prevent improper cooling and thermal damage, do not operate the server unless all bays are populated with either a component or a blank. To remove the component: Back up all server data on the drive. Power down the server (on page 24).

  • Page 28: Non-Hot-Plug Drive

    Remove the non-hot-plug drive cage. To replace the component, reverse the removal procedure. Non-hot-plug drive CAUTION: To prevent improper cooling and thermal damage, do not operate the server unless all bays are populated with either a component or a blank. To remove the component: Back up all server data on the drive.

  • Page 29: Hot-Plug Drive Blanks

    Remove the non-hot-plug drive. To replace the component, reverse the removal procedure. Hot-plug drive blanks CAUTION: To prevent improper cooling and thermal damage, do not operate the server unless all bays are populated with either a component or a blank. To remove the component: Remove the front bezel (on page 25).

  • Page 30: Hot-Plug Drive

    Hot-plug SFF drive blank To replace the SFF drive blank, while pressing the release latch, slide the component into the bay until it is fully seated. Hot-plug drive CAUTION: To prevent improper cooling and thermal damage, do not operate the server unless all bays are populated with either a component or a blank.
  • Page 31 WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the internal system components to cool before touching them. To remove the component: Power down the server (on page 24). Remove all power: Disconnect each power cord from the power source. Disconnect each power cord from the server.

  • Page 32: 8-Bay Sff Hot-Plug Drive Cage

    Box 2 To replace the component, reverse the removal procedure. 8-bay SFF hot-plug drive cage WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the internal system components to cool before touching them. To remove the component: Power down the server (on page 24).

  • Page 33: M.2 Ssd Enablement Kit

    Box 1 Box 2 To replace the component, reverse the removal procedure. M.2 SSD enablement kit M.2 SSD enablement option WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives, power input modules, and the internal system components to cool before touching them. CAUTION: To prevent damage to electrical components, take the appropriate anti-static precautions before beginning any system installation.
  • Page 34 To remove the component: Power down the server (on page 24). Remove all power: Disconnect each power cord from the power source. Disconnect each power cord from the server. Place the server on its side. Remove the access panel (on page 24). If installed, remove the PCI air baffle (on page 25).

  • Page 35: M.2 Ssd Module

    M.2 SSD module WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives, power input modules, and the internal system components to cool before touching them. CAUTION: To prevent damage to electrical components, take the appropriate anti-static precautions before beginning any system installation.
  • Page 36 Disconnect the power and SATA cable. Release cables from clip and metal tabs. Press the metal tab. Removal and replacement procedures 36...

  • Page 37: Fans

    Remove the optical drive and disconnect the cable from the rear of the drive. To replace the component, reverse the removal procedure. Fans System fan module (92 x 32 mm) To remove the component: Power down the server (on page 24). Remove all power: Disconnect each power cord from the power source.

  • Page 38: Upgrade Fan Module (92 X 38 Mm)

    Remove the 92 × 32 mm system fan module. To replace the component, reverse the removal procedure. Upgrade fan module (92 x 38 mm) To remove the component: Power down the server (on page 24). Remove all power: Disconnect each power cord from the power source. Disconnect each power cord from the server.

  • Page 39: Pci Fan Module

    Remove the 92 × 38 mm system fan module. To replace the component, reverse the removal procedure. PCI fan module CAUTION: For proper cooling do not operate the server without the access panel, baffles, expansion slot covers, or blanks installed. To remove the component: Power down the server (on page 24).

  • Page 40: Gpu Supporting Holder

    Disconnect the fan power cable and remove the PCI fan. To replace the component, reverse the removal procedure. GPU supporting holder To remove the component: Power down the server (on page 24). Remove all power: Disconnect each power cord from the power source. Disconnect each power cord from the server.

  • Page 41: Fbwc Module

    Remove the GPU with the supporting holder from slot 1: Open the PCIe slot cover retainer. Loosen the captive screw of the supporting holder. Open the latch on the slot 1 and remove the GPU. Remove the supporting holder. To replace the component, reverse the removal procedure. FBWC module WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the internal system components to cool before touching them.
  • Page 42 CAUTION: To prevent damage to electrical components, take the appropriate anti-static precautions before beginning any installation, removal, or replacement procedure. Improper grounding can cause electrostatic discharge. To remove the component: Power down the server (on page 24). Remove all power: Disconnect each power cord from the power source.

  • Page 43: Smart Storage Battery

    Remove the cache module. To replace the component, reverse the removal procedure. Smart Storage Battery WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the internal system components to cool before touching them. CAUTION: To prevent damage to electrical components, take the appropriate anti-static precautions before beginning any installation, removal, or replacement procedure.

  • Page 44: Dimms

    Single-rank and dual-rank PC4-2400T (DDR4-2400) RDIMMs operating at up to 2400 MT/s For the latest memory configuration information, see the product QuickSpecs on the Hewlett Packard Enterprise website (http://www.hpe.com/info/qs). Removing a DIMM WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives, power input modules, and the internal system components to cool before touching them.

  • Page 45: Heatsink

    Remove the access panel (on page 24). If installed, remove the PCI air baffle (on page 25). Remove the system air baffle (on page 26). Open the DIMM slot latches. Remove the DIMM. To replace the component, reverse the removal procedure. Heatsink To remove the component: Power down the server (on page 24).
  • Page 46 Remove the heatsink from the processor backplate. To replace the component: Clean the old thermal grease from the processor with the alcohol swab. Allow the alcohol to evaporate before continuing. Remove the thermal interface protective cover from the heatsink. Install the heatsink: Position the heatsink on the processor backplate.

  • Page 47: Processor

    Finish the installation by completely tightening the screws in the same sequence. Install the system air baffle. If removed, install the PCI air baffle. Install the access panel. Return the server to an upright position. Connect each power cord to the server. Connect each power cord to the power source.
  • Page 48 Place the server on its side. Remove the access panel (on page 24). If installed, remove the PCI air baffle (on page 25). Remove the system air baffle (on page 26). Remove the heatsink: Loosen one pair of diagonally opposite screws halfway, and then loosen the other pair of screws.
  • Page 49 Remove the processor from the processor retaining bracket. To replace the component: Install the processor. Verify that the processor is fully seated in the processor retaining bracket by visually inspecting the processor installation guides on either side of the processor. THE PINS ON THE SYSTEM BOARD ARE VERY FRAGILE AND EASILY DAMAGED.
  • Page 50 Close the processor retaining bracket. When the processor is installed properly inside the processor retaining bracket, the processor retaining bracket clears the flange on the front of the socket. Press and hold the processor retaining bracket in place, and then close each processor locking lever.

  • Page 51: System Board

    Finish the installation by completely tightening the screws in the same sequence. Install the system air baffle. If removed, install the PCI air baffle. Install the access panel. Return the server to an upright position. Connect each power cord to the server. Connect each power cord to the power source.
  • Page 52 Remove the heatsink: Loosen one pair of diagonally opposite screws halfway, and then loosen the other pair of screws. Completely loosen all screws in the same sequence. Remove the heatsink from the processor backplate. Removal and replacement procedures 52...
  • Page 53 Open each of the processor locking levers in the order indicated, and then open the processor retaining bracket. CAUTION: THE PINS ON THE SYSTEM BOARD ARE VERY FRAGILE AND EASILY DAMAGED. To avoid damage to the system board, do not touch the processor or the processor socket contacts.
  • Page 54 Remove the failed system board. To replace the system board: Install the system board. Removal and replacement procedures 54...
  • Page 55 Open each of the processor locking levers in the order indicated in the following illustration, and then open the processor retaining bracket. Remove the clear processor socket cover. Retain the processor socket cover for future use. CAUTION: THE PINS ON THE SYSTEM BOARD ARE VERY FRAGILE AND EASILY DAMAGED.
  • Page 56 Install the processor. Verify that the processor is fully seated in the processor retaining bracket by visually inspecting the processor installation guides on either side of the processor. THE PINS ON THE SYSTEM BOARD ARE VERY FRAGILE AND EASILY DAMAGED. Close the processor retaining bracket.
  • Page 57 Apply all the grease to the top of the processor in the following pattern to ensure even distribution. Install the heatsink: Position the heatsink on the processor backplate. Tighten one pair of diagonally opposite screws halfway, and then tighten the other pair of screws.

  • Page 58: System Battery

    Power up the server. IMPORTANT: Install all components with the same configuration that was used on the failed system board. After you replace the system board, you must re-enter the server serial number and the product ID: During the server startup sequence, press the F9 key to access UEFI System Utilities. Select System Configuration >...

  • Page 59: Dedicated Ilo Port Management Module

    Remove the battery. IMPORTANT: Replacing the system board battery resets the system ROM to its default configuration. After replacing the battery, reconfigure the system through RBSU. To replace the component, reverse the removal procedure. For more information about battery replacement or proper disposal, contact an authorized reseller or an authorized service provider.

  • Page 60: Enabling The Dedicated Ilo Management Module

    Enabling the dedicated iLO management module The onboard NIC 1/shared iLO connector is set as the default system iLO connector. To enable the dedicated iLO management module, use the iLO 4 Configuration Utility accessible within the HPE UEFI System Utilities.

  • Page 61: Hpe Atx 350-W Power Supply (Non-Hot-Plug)

    HPE ATX 350-W Power Supply (non-hot-plug) WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the internal system components to cool before touching them. CAUTION: To prevent damage to electrical components, take the appropriate anti-static precautions before beginning any installation, removal, or replacement procedure.

  • Page 62: Rps Enablement Kit

    To remove the component: Power down the server (on page 24). Remove all power: Disconnect each power cord from the power source. Disconnect each power cord from the server. Place the server on its side. Remove the access panel (on page 24). If installed, remove the PCI air baffle (on page 25).
  • Page 63 CAUTION: To prevent damage to electrical components, properly ground the server before beginning any installation procedure. Improper grounding can cause ESD. CAUTION: To prevent improper cooling and thermal damage, do not operate the server unless all bays are populated with either a component or a blank. To remove the component: Power down the server (on page 24).

  • Page 64: Hpe Redundant Power Supply Input Module

    Disconnect all power supply cables from the system board, drive cages, and devices. Remove the hot-plug power input module. Remove the RPS backplane. Remove the RPS bracket from the bay. To replace the component, reverse the removal procedure. HPE redundant power supply input module Removal and replacement procedures 64...
  • Page 65 WARNING: To reduce the risk of electric shock or damage to the equipment: • Do not disable the power cord grounding plug. The grounding plug is an important safety feature. • Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all times.

  • Page 66: Redundant Power Supply Blank

    Remove the strain relief clip from RPS and retain the clip for future use. Remove all power: Disconnect each power cord from the power source. Disconnect each power cord from the server. Place the server on a sturdy, level surface. Remove the access panel (on page 24).

  • Page 67: Hp Trusted Platform Module

    To remove the component: Power down the server (on page 24). Access the product rear panel. WARNING: To reduce the risk of personal injury from hot surfaces, allow the power supply or power supply blank to cool before touching it. Remove the power supply blank.

  • Page 68: Troubleshooting

    • Simplified Chinese (http://www.hpe.com/support/Gen9_TSG_zh_cn) The HPE ProLiant Gen9 Troubleshooting Guide, Volume II: Error Messages provides a list of error messages and information to assist with interpreting and resolving error messages on ProLiant servers and server blades. To view the guide, select a language: •...

  • Page 69: Diagnostic Tools

    This feature is supported on servers that support external video and have a UID button or an SUV connector. When power is available to the server but the server is not powered on, iLO runs on auxiliary power and can take control of the server video adapter to display the HPE ProLiant Pre-boot Health Summary.

  • Page 70: Integrated Management Log

    The IML records hundreds of events and stores them in an easy-to-view form. The IML timestamps each event with 1-minute granularity. You can view recorded events in the IML in several ways, including the following: • From within HPE SIM • From within the UEFI System Utilities (on page 70) •...

  • Page 71: Embedded Diagnostics Option

    For more information on the Embedded Diagnostics option, see the UEFI System Utilities user guide for your server on the Hewlett Packard Enterprise website (http://www.hpe.com/info/UEFI/docs). Re-entering the server serial number and product ID After you replace the system board, you must re-enter the server serial number and the product ID: During the server startup sequence, press the F9 key to access UEFI System Utilities.

  • Page 72: Insight Diagnostics Survey Functionality

    HPE Insight Remote Support Hewlett Packard Enterprise strongly recommends that you register your device for remote support to enable enhanced delivery of your Hewlett Packard Enterprise warranty, HPE support services, or Hewlett Packard Enterprise contractual support agreement. Insight Remote Support supplements your...

  • Page 73: External Usb Functionality

    HPE ProLiant Gen8 servers, HPE SSA replaces ACU with an enhanced GUI and additional configuration features. The HPE SSA exists in three interface formats: the HPE SSA GUI, the HPE SSA CLI, and HPE SSA Scripting. Although all formats provide support for configuration tasks, some of the advanced tasks are available in only one format.

  • Page 74: Component Identification

    Component identification Front panel components Item Description Optical drive (optional) Box 2 Box 1 USB 3.0 connectors Front panel LEDs and buttons Component identification 74...

  • Page 75: Front Panel Led Power Fault Codes

    3 flashes Memory 4 flashes Riser board PCIe slots 5 flashes FlexibleLOM 6 flashes Removable HPE Flexible Smart Array controller/Smart SAS HBA controller 7 flashes System board PCIe slots 8 flashes Power backplane or storage backplane 9 flashes Power supply For more information, see "Front panel LEDs and buttons (on page 74)."...

  • Page 76: Rear Panel Components

    Rear panel components Item Description Non-hot-plug power supply Kensington security slot Padlock slot Power supply bay 1 of the hot-plug power supply (optional) Power supply bay 2 of the hot-plug power supply (optional) NIC connector 1 NIC connector 2 Dedicated iLO port (optional) Slot 5 PCIe3x8 (8, 4, 1) Slot 4 PCIe3x4 (4, 1) Slot 3 PCIe3x8 (8, 4, 1)

  • Page 77: Rear Panel Leds

    Rear panel LEDs Item Description Status Power supply LED Solid green = Normal Off = One or more of the following conditions exists: • Power is unavailable • Power supply failed • Power supply is in standby mode • Power supply error iLO link LED Green = Linked to network Off = No network connection...

  • Page 78: System Board Components

    System board components Item Description Fan connector 3 Fan connector 2 DIMM slots 24-pin power supply connector RPSU connector Processor 4-pin power supply connector Front I/O connector Fan connector 1 Mini-SAS connector 1 Front USB 3.0 connector SATA connector 2 (for M.2 SSD 2) Mini-SAS connector 2 SATA connector 1 (for M.2 SSD 1 or optical drive) Internal USB 3.0 connector...

  • Page 79: System Maintenance Switch

    Item Description System maintenance switch TPM connector NMI header Dedicated iLO port connector Slot 5 PCIe3 x8 (8, 4, 1) Slot 4 PCIe3 x4 (4, 1) microSD card slot Slot 3 PCIe3 x8 (8, 4, 1) Slot 2 PCIe3 x4 (4, 1) Slot 1 PCIe3 x16 (16, 8, 4, 1) System maintenance switch Position...

  • Page 80: Dimm Slot Locations

    Short the NMI header ("System board components" on page 78). For more information, see the Hewlett Packard Enterprise website (http://www.hpe.com/support/NMI- CrashDump). DIMM slot locations DIMM slots are numbered sequentially (1 through 8) for the processor. The supported AMP modes use the letter assignments for population guidelines.

  • Page 81: Drive Numbering

    Item Description Default system fan (92 x 32 mm) Upgrade system fan (92 x 38 mm) The option is required to replace the default system fan when a 140 W workstation processor or SAS SSD drives are installed. PCI fan The PCI fan is part of the PCI fan and baffle option.

  • Page 82: Hot-Plug Drive Led Definitions

    • Four-bay LFF hot-plug drive model • Eight-bay SFF hot-plug drive model Hot-plug drive LED definitions Component identification 82...
  • Page 83 Item Status Definition Locate Solid blue The drive is being identified by a host application. Flashing blue The drive carrier firmware is being updated or requires an update. Activity ring Rotating green Drive activity. No drive activity. Do not remove Solid white Do not remove the drive.

  • Page 84: Cabling

    For information on cabling peripheral components, refer to the white paper on high-density deployment at the Hewlett Packard Enterprise website (http://www.hpe.com/info/servers). CAUTION: When routing cables, always be sure that the cables are not in a position where they can be pinched or crimped.

  • Page 85: 4-Bay Lff Hot-Plug Drive Cabling

    4-bay LFF hot-plug drive cabling • Box 1 drive backplane connected to the system board Item Description Drive power cable Mini-SAS cable • Box 2 drive backplane connected the system board Item Description Drive power cable Mini-SAS cable Cabling 85...
  • Page 86 • Box 1 and box 2 drive backplanes connected to an H240 adapter Item Description Box 2 drive power cable Box 1 drive power cable Mini-SAS cable to port 2 of the controller Mini-SAS cable to port 1of the controller •...

  • Page 87: 8-Bay Sff Hot-Plug Drive Cabling

    • Box 1 and box 2 drive backplane connected to a P840 controller Item Description Box 2 drive power cable Box 1 drive power cable Mini-SAS Y-cable to port 1 of the controller 8-bay SFF hot-plug drive cabling • Box 1 drive backplane connected to the system board Item Description Drive power cable...
  • Page 88 • Box 1 drive backplane connected to an H240 adapter Item Description Drive power cable Mini-SAS port 1 connection to port 1 controller Mini-SAS port 2 connection to port 2 controller • Box 2 drive backplane connected to an H240 adapter Item Description Drive power cable...
  • Page 89 • Box 1 drive backplane connected to a P440 controller Item Description Drive power cable Mini-SAS Y-cable to controller • Box 2 drive backplane connected to a P440 controller Item Description Drive power cable Mini-SAS Y-cable to controller Cabling 89...
  • Page 90 • Box 1 drive backplane connected to a P840 controller Item Description Drive power cable Mini-SAS Y-cable connection to port 1 controller • Box 2 drive backplane connected to a P840 controller Item Description Drive power cable Mini-SAS Y-cable connection to port 2 controller Cabling 90...

  • Page 91: M.2 Ssd Cabling

    M.2 SSD cabling Item Description M.2 SSD 2 SATA cable M.2 SSD 1 SATA cable FBWC module cabling The FBWC solution is a separately purchased option. This server only supports FBWC module installation when a Smart Array P-Series controller is installed. Depending on the controller option installed, the actual storage controller connectors might look different from what is shown in this section.

  • Page 92: Smart Storage Battery Cabling

    • FBWC module on a P840 controller Smart Storage Battery cabling Cabling 92...

  • Page 93: Optical Drive Cabling

    Optical drive cabling Item Description Power supply cable Drive power cable SATA cable GPU cabling Cabling 93...

  • Page 94: Fan Cabling

    Fan cabling • Default system fan (92 x 32 mm) • Optional system upgrade fan (92 x 38 mm) Cabling 94...

  • Page 95: Power Supply Cabling

    • PCI fan Power supply cabling HPE ATX 350 W power supply (non-hot-plug) Item Description 8-pin power supply cable to box 2 drive backplane and optical drive 8-pin power supply cable to box 1 drive backplane 4-pin power cable to system board...

  • Page 96: Hpe Atx 550 W Power Supply (Non-Hot-Plug)

    HPE ATX 550 W power supply (non-hot-plug) Item Description 8-pin power supply cable to box 2 drive backplane and optical drive 6-pin power cable to GPU 8-pin power supply cable to box 1 drive backplane 4-pin power cable to system board...

  • Page 97: Front I/O Cabling

    Item Description 6-pin power cable to GPU 4-pin power cable to system board RPS cable to system board 24-pin power cable to system board Front I/O cabling Front USB 3.0 cabling Cabling 97...

  • Page 98: Specifications

    40°C to 45°C (104°F to 113°F) at sea level with an altitude derating of 1.0°C per every 125 m (1.8°F per every 410 ft) above 900 m (2953 ft) to a maximum of 3048 m (10,000 ft). The approved hardware configurations for this system are listed on the Hewlett Packard Enterprise website (http://www.hpe.com/servers/ASHRAE). Server specifications Specification Value —...

  • Page 99: Power Supply Specifications

    • 750 W Common Slot Gold Hot Plug Power Supply (512327-B21) This is supported when the two-bay HPE RPS Enablement option (PN 784582-B21) is installed. These are Entry Level Power Supply products for ProLiant servers. For more information about the power supply features, specifications, and compatibility, see the Hewlett Packard Enterprise website (http://www.hpe.com/servers/powersupplies).

  • Page 100: Acronyms And Abbreviations

    American Society of Heating, Refrigerating and Air-Conditioning Engineers backplane Customer Self Repair file allocation table FBWC flash-backed write cache graphics processing unit host bus adapter HPE SIM HPE Systems Insight Manager Integrated Lights-Out Integrated Management Log large form factor Acronyms and abbreviations 100...
  • Page 101 Lights-Out Management nonmaskable interrupt NVRAM nonvolatile memory Optical Disk Drive PCIe Peripheral Component Interconnect Express POST Power-On Self-Test RBSU ROM-Based Setup Utility REST representational state transfer redundant power supply serial attached SCSI SATA serial ATA Secure Digital small form factor Systems Insight Manager Service Pack for ProLiant Acronyms and abbreviations 101...
  • Page 102 Trusted Platform Module UEFI Unified Extensible Firmware Interface unit identification universal serial bus Acronyms and abbreviations 102...

  • Page 103: Documentation Feedback

    Hewlett Packard Enterprise is committed to providing documentation that meets your needs. To help us improve the documentation, send any errors, suggestions, or comments to Documentation Feedback (mailto:docsfeedback@hpe.com). When submitting your feedback, include the document title, part number, edition, and publication date located on the front cover of the document. For online help content, include the product name, product version, help edition, and publication date located on the legal notices page.

  • Page 104: Index

    HPE Insight Online 72 diagnostic tools 69, 70, 71, 73 HPE Insight Remote Support software 72 diagnostics utility 71 HPE SIM (HPE Systems Insight Manager) 70 dimensions and weight 98 HPE SSA (HPE Smart Storage Administrator) 73 DIMM slot locations 80...
  • Page 105 DRAFT – Confidential - DRAFT iLO (Integrated Lights-Out) 69, 70 power cabling 84, 95 iLO 4 (Integrated Lights-Out 4) 69 power calculator 99 iLO activity LED 77 power fault 75 iLO connector 74 Power On/Standby button 74 iLO link LED 77 power supplies 95, 96 IML (Integrated Management Log) 70 power supply cabling 95...
  • Page 106 DRAFT – Confidential - DRAFT system configuration settings 79 system fan 37 system maintenance switch 79 technical support 5 temperature requirements 98 TPM (Trusted Platform Module) 67 TPM, connector 78 troubleshooting 68 troubleshooting resources 68, 69 troubleshooting, firmware upgrade utility 68 Trusted Platform Module (TPM) 67 UEFI System Utilities 70 UID (unit identification) 74, 77...
