TD20 Series VFD
Function
Name
code
HDI input
P17.22
frequency
PID reference
P17.23
value
PID feedback
P17.24
value
Power factor
P17.25
of the motor
Current
P17.26
running time
Simple PLC
and the
current stage
P17.27
of the
multi-step
speed
ASR controller
P17.28
output
P17.29 Reserved
P17.30 Reserved
P17.31 Reserved
Magnetic flux
P17.32
linkage
Exciting
P17.33 current
reference
Torque current
P17.34
reference
Detailed instruction of parameters
Display HDI input frequency
Range: 0.00–50.00kHz
Display PID reference value
Range: -100.0–100.0%
Display PID feedback value
Range: -100.0–100.0%
Display the current power factor of the motor.
Range: -1.00–1.00
Display the current running time of the VFD.
Range: 0–65535min
Display simple PLC and the current stage of the
multi-step speed
Range: 0–15
The percentage of the rated torque of the relative motor,
display ASR controller output
Range: -300.0%–300.0% (the rated motor current)
Display the magnetic flux linkage of the motor.
Range: 0.0%–200.0%
Display the exciting current reference in the vector
control mode.
Range: -3000.0–3000.0A
Display the torque current reference in the vector control
mode.
Range: -3000.0–3000.0A
