TECHTOP TD20 Series Product Manual page 84

TD20 Series VFD
Function
Name
code
Output torque
P17.09
The motor
P17.10 frequency
evaluation
DC bus
P17.11
voltage
Switch input
P17.12
terminals state
Switch output
P17.13
terminals state
Digital
P17.14
adjustment
Torque
P17.15
reference
P17.16 Linear speed
P17.17 Reserved
Counting
P17.18
value
AI1 input
P17.19
voltage
AI2 input
P17.20
voltage
AI3 input
P17.21
voltage
Detailed instruction of parameters
Setting range: -300.0%–300.0%
(the rated current of the motor)
Display the current output torque of the VFD.
Range: -250.0–250.0%
Evaluate the motor rotor frequency on open loop vector
Range: 0.00– P00.03
Display current DC bus voltage of the VFD
Range: 0.0–2000.0V
Display current Switch input terminals state of the VFD
Range: 0000–00FF
Display current Switch output terminals state of the VFD
Range: 0000–000F
Display the adjustment through the keypad of the VFD.
Range: 0.00Hz–P00.03
Display the torque reference, the percentage to the
current rated torque of the motor.
Setting range: -300.0%–300.0%
(the rated current of the motor)
Display the current linear speed of the VFD.
Range: 0–65535
Display the current counting number of the VFD.
Range: 0–65535
Display analog AI1 input signal
Range: 0.00–10.00V
Display analog AI2 input signal
Range: 0.00–10.00V
Display analog AI2 input signal
Range: -10.00–10.00V
-82-
Function Parameters
Default
Modify
value
●
●
●
●
●
●
●
●
●
●
●
●
●
