TECHTOP TD20 Series Product Manual page 33

TD20 Series VFD
Function
Name
code
The braking
P01.03 current before
starting
The braking
P01.04 time before
starting
ACC/DEC
P01.05
selection
ACC time of
the starting
P01.06
step of S
curve
DEC time of
the ending
P01.07
step of S
curve
P01.08 Stop selection
Detailed instruction of parameters
Setting range: 0.0–50.0s
The VFD will carry out DC braking at the braking current
set before starting and it will speed up after the DC
braking time. If the DC braking time is set to 0, the DC
braking is invalid.
The stronger the braking current, the bigger the braking
power. The DC braking current before starting means
the percentage of the rated current of the VFD.
The setting range of P01.03: 0.0–100.0%
The setting range of P01.04: 0.00–50.00s
The changing mode of the frequency during start-up and
running.
0: Linear type
The output frequency increases or decreases linearly.
Output frequency
fmax
t1
1: S curve
0.0–50.0s
Output frequency
0: Decelerate to stop: after the stop command becomes
valid, the VFD decelerates to reduce the output
frequency during the set time. When the frequency
T
t2
t1=P01.06
t2=P01.07
T
t3=P01.06
t4=P01.07
3 4
-31-
Function Parameters
Default
Modify
value
◎
0.0%
◎
0.00s
◎
0
◎
0.1s
◎
0.1s
○
0
