TECHTOP TD20 Series Product Manual page 124

TD20 Series VFD
Model
TD20-0R4G-S1
TD20-0R7G-S1
TD20-1R1G-S1
TD20-0R4G-S2
TD20-0R7G-S2
TD20-1R5G-S2
TD20-2R2G-S2
TD20-0R4G-2
TD20-0R7G-2
TD20-0R7G-4
TD20-1R5G-4
TD20-2R2G-4
All models
@@: See marking on product for tightening torque detail.
##: UL listed wire connector shall be used.
The models TD20-0R4G-S2/TD20-0R7G-S2/TD20-1R5G-S2 use terminal blocks of ANYTEK and
DEGSON, and the tightening torque must be 8.8 in-lb (ANYTEK) and 4.4 in-lb (DEGSON) or equivalent.
The model TD20-2R2G-S2 uses terminal blocks of DEGSON, and the tightening torque must be 4.4
in-lb or equivalent.
The models TD20-0R4G-2/TD20-0R7G-2/TD20-0R7G-4/TD20-1R5G-4/TD20-2R2G-4 use terminal
blocks of SUCCEED, and the tightening torque must be 7 in-lb or equivalent.
Tightening torque and wire range for field grounding wiring terminals are marked adjacent to the terminal
or on the wiring diagram.
Model
TD20-0R4G-S1
TD20-0R7G-S1
TD20-1R1G-S1
TD20-0R4G-S2
TD20-0R7G-S2
TD20-1R5G-S2
TD20-2R2G-S2
TD20-0R4G-2
Terminal Type
Input and Output
Terminal
Input and Output
Terminal
Input and Output
Terminal
Input and Output
Terminal
Input and Output
Terminal
Control Terminal
Block
Required Torque (in-lbs)
10
10
10
10
10
10
10
10
-122-
Appendix C Peripheral Options and Parts
Required
Wire
Torque
Range
(in-lbs)
4.4 or 8.8
14 AWG
@@
4.4 or 8.8
14 AWG
@@
4.4 or 8.8
12 AWG
@@
4.4@@ 12 AWG
7 14 AWG
26-14
4.5 (Str/Sol)
AWG
Wire Range (AWG)
Wire
Connector
(##)
Optional
Optional
Required
Required
Optional
Optional
14
14
14
14
12
12
10
14
