TECHTOP TD20 Series Product Manual page 68

TD20 Series VFD
Function
Name
code
Integral ratio
P08.43 of the keypad
potentiometer
UP/DOWN
P08.44 terminals
control setting
UP terminals
P08.45 frequency
changing ratio
DOWN
P08.46 terminals
frequency
Detailed instruction of parameters
3: Neither ∧/∨ keys nor digital potentiometer
adjustments are valid
LED tens: frequency control selection
0: Only valid when P00.06=0 or P00.07=0
1: Valid for all frequency setting manner
2: Invalid for multi-step speed when multi-step speed
has the priority
LED hundreds: action selection during stopping
0: Setting is valid
1: Valid during running, cleared after stopping
2: Valid during running, cleared after receiving the stop
command
LED thousands: ∧/∨ keys and analog potentiometer
integral function
0: The Integral function is valid
1: The Integral function is invalid
0.01–10.00s
0x00–0x221
LED ones: frequency control selection
0: UP/DOWN terminals setting valid
1: UP/DOWN terminals setting valid
LED tens: frequency control selection
0: Only valid when P00.06=0 or P00.07=0
1: All frequency means are valid
2: When the multi-step are priority, it is invalid to the
multi-step
LED hundreds: action selection when stop
0: Setting valid
1: Valid in the running, clear after stop
2: Valid in the running, clear after receiving the stop
commands
0.01–50.00s
0.01–50.00s
-66-
Function Parameters
Default
Modify
value
○
0.10s
○
0x000
○
0.50 s
○
0.50 s
