TD20 Series VFD
Function
Name
code
short circuit
Braking
retention
P13.14 time of
starting
short circuit
Braking
retention
P13.15 time of
stopping
short circuit
P14 Group Serial communication
local
P14.00 communicatio
n address
Communicatio
P14.01
n baud ratio
Digital bit
P14.02
checkout
Detailed instruction of parameters
After the VFD stops, when the operation frequency is
less than P01.09, set P13.15 to non-zero value and
begin stopping short-circuit braking and then DC
braking.
Setting range of P13.13: 0.0–150.0% (VFDs)
Setting range of P13.14: 0.00–50.00s
Setting range: 1–247
When the master is writing the frame, the
communication address of the slave is set to 0; the
broadcast address is the communication address. All
slaves on the MODBUS fieldbus can receive the frame,
but the salve doesn't answer.
The communication address of the VFD is unique in the
communication net. This is the fundamental for the point
to point communication between the upper monitor and
the VFD.
Note: The address of the slave cannot set to 0.
Set the digital transmission speed between the upper
monitor and the VFD.
0: 1200BPS
1: 2400BPS
2: 4800BPS
3: 9600BPS
4: 19200BPS
5: 38400BPS
6: 57600BPS
Note: The baud rate between the upper monitor and the
VFD must be the same. Otherwise, the communication
is not applied. The bigger the baud rate, the quicker the
communication speed.
The data format between the upper monitor and the VFD
must be the same. Otherwise, the communication is not
-79-
Function Parameters
Default
Modify
value
○
0.00s
○
0.00s
○
1
○
4
○
1
