TD20 Series VFD
Function
Name
code
previous 2
faults
Output
terminals state
P07.56
at previous 2
faults
P08 Group Enhanced functions
P08.00
ACC time 2
P08.01
DEC time 2
P08.02
ACC time 3
P08.03
DEC time 3
P08.04
ACC time 4
P08.05
DEC time 4
Jogging
P08.06
running
frequency
Jogging
P08.07
running ACC
time
Jogging
P08.08
running DEC
time
Jumping
P08.09
frequency 1
jumping
P08.10
frequency
Detailed instruction of parameters
Refer to P00.11 and P00.12 for detailed definition.
TD20 series define four groups of ACC/DEC time which
can be selected by P5 group. The first group of
ACC/DEC time is the factory default one.
Setting range: 0.0–3600.0s
This parameter is used to define the reference
frequency during jogging.
Setting range: 0.00Hz–P00.03 (the Max. frequency)
The jogging ACC time means the time needed if the
VFD runs from 0Hz to the Max. Frequency.
The jogging DEC time means the time needed if the
VFD goes from the Max. Frequency (P00.03) to 0Hz.
Setting range: 0.0–3600.0s
When the set frequency is in the range of jumping
frequency, the VFD will run at the edge of the jumping
frequency.
The VFD can avoid the mechanical resonance point by
-61-
Function Parameters
Default
Modify
value
0
Depend
on
model
Depend
on
model
Depend
on
model
Depend
on
model
Depend
on
model
Depend
on
model
5.00Hz
Depend
on
model
Depend
on
model
0.00Hz
0.00Hz
