TECHTOP TD20 Series Product Manual page 41

TD20 Series VFD
Function
Name
code
coefficient I
Torque setting
P03.11
method
Keypad
P03.12
setting torque
Torque given
P03.13
filter time
Setting source
of forward
rotation
P03.14
upper-limit
frequency in
torque control
Setting source
of reverse
rotation
P03.15
upper-limit
frequency in
torque control
Torque control
forward
rotation
P03.16
upper-limit
frequency
keypad
Detailed instruction of parameters
value;
Only apply to the vector control mode without PG 0
(P00.00=0).
Setting range: 0–65535
This parameter is used to enable the torque control
mode, and set the torque setting means.
0: Torque control is invalid
1: Keypad setting torque (P03.12)
2: Analog AI1 setting torque
3: Analog AI2 setting torque
4: Analog AI3 setting torque
5: Pulse frequency HDI setting torque
6: Multi-step torque setting
7: MODBUS communication setting torque
8–10: Reserved
Note: Setting mode 2–7, 100% corresponds to 3 times
of the motor rated current
Setting range: -300.0%–300.0% (motor rated current)
0.000–10.000s
0: keypad setting upper-limit frequency (P03.16 sets
P03.14, P03.17 sets P03.15)
1: Analog AI1 setting upper-limit frequency
2: Analog AI2 setting upper-limit frequency
3: Analog AI3 setting upper-limit frequency
4: Pulse frequency HDI setting upper-limit frequency
5: Multi-step setting upper-limit frequency
6: MODBUS communication setting upper-limit
frequency
7–9: Reserved
Note: setting method 1–9, 100% corresponds to the
maximum frequency
This function is used to set the upper limit of the
frequency. P03.16 sets the value of P03.14; P03.17 sets
the value of P03.15.
Setting range: 0.00 Hz–P00.03 (the Max. output
frequency)
-39-
Function Parameters
Default
Modify
value
○
0
○
50.0%
○
0.100s
○
0
○
0
60.00
○
Hz
