TECHTOP TD20 Series Product Manual page 11

TD20 Series VFD
1
2
3
4
5
Serial No.
1 External keypad port
2
3
4 Hole for the sliding cover
5 Trunking board
6
7 Potentiometer knob
8 Control terminals
9 Main circuit terminals
10
11
12
Note: In above figure, the screws at 4 and 10 are provided with packaging and specific installation
depends on the requirements of customers.
Figure 2-3 Product structure
Name
Port cover
Cover
Nameplate
Screw hole
Cooling fan
Fan cover
Connect the external keypad
Protect the external keypad port
Protect the internal parts and components
Fix the sliding cover
Protect the inner components and fix the cables of the
main circuit
See Product Overview for detailed information
Refer to the Keypad Operation Procedure
See Electric Installation for detailed information
See Electric Installation for detailed information
Fix the fan cover and fan
See Maintenance and Hardware Fault Diagnose for
detailed information
Protect the fan
-9-
Product Overview
6
7
8
9
10
11
12
Illustration
