TD20 Series VFD
Function
Name
code
Polarity
selection of
P06.05
output
terminals
Y1 open delay
P06.06
time
Y1C off delay
P06.07
time
RO1 switching
P06.10
on delay time
RO1 switching
P06.11
off delay time
RO2 switching
P06.12
on delay time
RO2 switching
P06.13
off delay time
AO1 output
P06.14
selection
AO2 output
P06.15
selection
Detailed instruction of parameters
26: Establishment of DC bus voltage
27–30: Reserved
The function code is used to set the pole of the output
terminal.
When the current bit is set to 0, input terminal is positive.
When the current bit is set to 1, input terminal is
negative.
BIT3 BIT2
RO2 RO1
Setting range: 0–F
The setting range: 0.000–50.000s
The setting range: 0.000–50.000s
The function code defines the corresponding delay time
of the electrical level change during the programmable
terminal switching on and off.
RO electrical level
Invalid
RO valid
Switch-on
delay
Setting range: 0.000–50.000s
Note: P06.08 and P06.08 are valid only when
P06.00=1.
0: Running frequency
1: Setting frequency
2: Ramp reference frequency
3: Running rotation speed (relative to 2 times the
rotating speed of the motor)
4: Output current (relative to 2 times rated current of the
VFD)
5: Output current (relative to 2 times rated current of the
motor)
6: Output voltage (relative to 1.5 times the rated voltage
of the VFD)
7: Output power (relative to 2 times the rated power of
the motor)
BIT1
Reserved
Valid
Switch-off
delay
-52-
Function Parameters
Default
value
0
BIT0
Y1
0.000s
0.000s
0.000s
0.000s
0.000s
Invalid
0.000s
0
0
Modify
○
○
○
○
○
○
○
○
○
