TD20 Series VFD
Function
Name
code
P05 Group Input terminals
HDI input
P05.00
selection
S1 terminals
P05.01
function
selection
S2 terminals
P05.02
function
selection
S3 terminals
P05.03
function
selection
S4 terminals
P05.04
function
selection
S5 terminals
P05.05
function
selection
S6 terminals
P05.06
function
selection
S7 terminals
P05.07
function
selection
S8 terminals
P05.08
function
selection
HDI terminals
P05.09
function
selection
Detailed instruction of parameters
0: HDI is high pulse input. See P05.49–P05.54
1: HDI is switch input
Note: S1–S4, HDI are the upper terminals on the control
board and P05.12 can be used to set the function of
S5–S8
0: No function
1: Forward rotation operation
2: Reverse rotation operation
3: 3-wire control operation
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Operation pause
9: External fault input
10: Increasing frequency setting (UP)
11: Decreasing frequency setting (DOWN)
12: Cancel the frequency change setting
13: Shift between A setting and B setting
14: Shift between combination setting and A setting
15: Shift between combination setting and B setting
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi- stage speed terminal 4
20: Multi- stage speed pause
21: ACC/DEC time 1
22: ACC/DEC time 2
23: Simple PLC stop reset
24: Simple PLC pause
25: PID control pause
26: Traverse Pause (stop at the current frequency)
27: Traverse reset (return to the center frequency)
28: Counter reset
29: Torque control prohibition
30: ACC/DEC prohibition
31: Counter trigger
32: Reserve
-45-
Function Parameters
Default
Modify
value
0
1
4
7
0
0
0
0
0
0
