TECHTOP TD20 Series Product Manual page 108

TD20 Series VFD
Function
instruction
SW 1 of the VFD
SW 1 of the VFD
Fault code of the
VFD
Identifying code of
the VFD
Setting frequency
Bus voltage
Output voltage
Output current
Operation speed
Output power
Output torque
PID setting
PID feedback
Input IO state
Output IO state
Address
definition
(0–1000, 1000 corresponds to the 100.0% of
the rated voltage of the motor)
AO output setting 1
200DH
(-1000–1000, 1000 corresponds to 100.0%)
AO output setting 2
200EH
(-1000–1000, 1000 corresponds to 100.0%)
0001H: forward running
0002H: forward running
0003H: stop
2100H
0004H: fault
0005H: POFF state
0006H: pre-exciting state
Bit0: =0: bus voltage is not established =1:
bus voltage is established
Bit1–2: =00: motor 1
Bit3: =0: asynchronous motor
2101H =1: synchronous motor
Bit4: =0: pre-alarm without overload
=1: overload pre-alarm
Bit5–Bit6: =00: keypad control
2102H See the fault type instruction
2103H TD20-----0x0106
3001H
3002H
3003H
3004H
Compatible with TD series, CHF100A and
3005H
CHV100
3006H
Compatible with TD series, CHF100A and
3007H
CHV100
3008H
3009H
300AH
300BH
Data meaning instruction
=01: motor 2
=10: motor 3 =11: motor 4
=01: terminal control
=10: communication control
-106-
Communication Protocol
R/W
characteristics
W
W
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
