TECHTOP TD20 Series Product Manual page 59

TD20 Series VFD
Function
Name
code
Rectifier
P07.11 bridge module
temperature
Convertering
P07.12 module
temperature
Software
P07.13
version
Local
P07.14 accumulative
running time
Most
significant digit
P07.15
of power
consumption
Least
significant digit
P07.16
of power
consumption
P07.17 Reserved
Rated power
P07.18
of the VFD
Rated voltage
P07.19
of the VFD
Rated current
P07.20
of the VFD
Factory bar
P07.21
code 1
Factory bar
P07.22
code 2
Detailed instruction of parameters
-20.0–120.0° C
-20.0–120.0° C
1.00–655.35
0–65535h
Display the power used by the VFD.
The power consumption of the VFD = P07.15 x 1000 +
P07.16
Setting range of P07.15: 0–65535kWh (x 1000)
Setting range of P07.16: 0.0–999.9kWh
Reserved
0.4–3000.0kW
Note: The value entered in this parameter must be in
kW.
Power (kW)
0.4
0.75
1.5
2.2
50–1200V
0.1–6000.0A
0x0000–0xFFFF
0x0000–0xFFFF
Horsepower (HP)
0.5
1
2
3
