TECHTOP TD20 Series Product Manual page 83

TD20 Series VFD
Function
Name
code
Communicatio
P14.06
n processing
P14.07 Reserved
P14.08 Reserved
P17 Group Monitoring function
Setting
P17.00
frequency
Output
P17.01
frequency
Ramp
P17.02 reference
frequency
P17.03 Output voltage
P17.04 Output current
P17.05 Motor speed
P17.06 Torque current
Magnetized
P17.07
current
P17.08 Motor power
Detailed instruction of parameters
3: No alarm and stop according to the stop means
(under all control modes)
0x00–0x11
LED ones:
0: Write with response: the VFD will respond to all
reading and writing commands of the upper monitor.
1: Write without response: the VFD only responds to the
reading command of the upper monitor. The
communication efficiency can be increased in this mode.
LED tens: (reserved)
0: Communication encrypting is invalid
1: Communication encrypting is valid
Display current set frequency of the VFD
Range: 0.00Hz–P00.03
Display current output frequency of the VFD
Range: 0.00Hz–P00.03
Display current ramp reference frequency of the VFD
Range: 0.00Hz–P00.03
Display current output voltage of the VFD
Range: 0–1200V
Display current output current of the VFD
Range: 0.0–5000.0A
Display the rotation speed of the motor.
Range: 0–65535RPM
Display current torque current of the VFD
Range: 0.0–5000.0A
Display current magnetized current of the VFD
Range: 0.0–5000.0A
Display current power of the motor.
-81-
Function Parameters
Default
Modify
value
○
0x00
●
●
●
●
●
●
●
●
●
●
●
