TECHTOP TD20 Series Product Manual page 57

TD20 Series VFD
Function
Name
code
selection
QUICK/JOG
the shifting
P07.03 sequence of
running
command
STOP/RST
P07.04
stop function
Displayed
parameters 1
P07.05
of running
state
Detailed instruction of parameters
1: Jogging
2: Switch display state via shift key
3: Switch between FWD/REV rotation
4: Clear UP/DOWN setting
5: Coast to stop
6: Switch running command ref. mode in order
7: Quick commission mode (based on non-default
parameter)
tens:
0: keys unlocked
1: Lock all keys
2: Lock part of the keys (lock PRG/ESC key only)
When P07.02=6, set the shifting sequence of running
command channels.
0: Keypad control→terminals control →communication
control
1: Keypad control←→terminals control
2: Keypad control←→communication control
3: Terminals control←→communication control
Select the stop function by STOP/RST. STOP/RST is
effective in any state for the keypad reset.
0: Only valid for the keypad control
1: Both valid for keypad and terminals control
2: Both valid for keypad and communication control
3: Valid for all control modes
0x0000–0xFFFF
BIT0: running frequency (Hz on)
BIT1: set frequency (Hz flickering)
BIT2: bus voltage (Hz on)
BIT3: output voltage (V on)
BIT4: output current (A on)
BIT5: running rotation speed (rpm on)
BIT6: output power (% on)
BIT7: output torque (% on)
BIT8: PID reference (% flickering)
BIT9: PID feedback value (% on)
BIT10: input terminals state
BIT11: output terminals state
BIT12: torque set value (% on)
-55-
Function Parameters
Default
Modify
value
○
0
○
0
○
0x03FF
