TD20 Series VFD
Function
Name
code
defined value
Torque control
reverse
rotation
P03.17 upper-limit
frequency
keypad
defined value
Upper-limit
setting of
P03.18
electromotion
torque
Upper-limit
P03.19 setting of
braking torque
Electromotion
torque
P03.20
upper-limit
keypad setting The function code is used to set the limit of the torque.
Braking
torque
P03.21
upper-limit
keypad setting
Weakening
coefficient in
P03.22
constant
power zone
The lowest
weakening
P03.23 point in
constant
power zone
P03.24 Max. voltage
Detailed instruction of parameters
This function code is used to select the electromotion
and braking torque upper-limit setting source selection.
0: Keypad setting upper-limit frequency (P03.20 sets
P03.18 and P03.21 sets P03.19)
1: Analog AI1 setting upper-limit torque
2: Analog AI2 setting upper-limit torque
3: Analog AI3 setting upper-limit torque
4: Pulse frequency HDI setting upper-limit torque
5: MODBUS communication setting upper-limit torque
6–8: Reserved
Note: Setting mode 1–8, 100% corresponds to three
times of the motor current.
Setting range: 0.0–300.0% (motor rated current)
The usage of motor in weakening control.
Function code P03.22 and P03.23 are effective at
constant power. The motor will enter into the weakening
state when the motor runs at rated speed. Change the
weakening curve by modifying the weakening control
coefficient. The bigger the weakening control coefficient
is, the steeper the weak curve is.
Setting range of P03.22: 0.1–2.0
Setting range of P03.23: 10%–100%
P03.24 set the Max. Voltage of the VFD, which is
-40-
Function Parameters
Default
Modify
value
60.00
○
Hz
○
0
○
0
○
180.0%
○
180.0%
○
0.3
○
20%
◎
100.0%
