TECHTOP TD20 Series Product Manual page 67

TD20 Series VFD
Function
Name
code
Energy
P08.37 Braking
enable
Energy
braking
P08.38
threshold
voltage
Cooling fan
P08.39
running mode
PWM
P08.40
selection
Over
P08.41 commission
selection
Keypad data
P08.42
control setting
Detailed instruction of parameters
This parameter is used to control the internal braking
unit.
0: Disabled
1: Enabled
Note: Only applied to internal braking unit.
After setting the original bus voltage of energy braking,
you can adjust the voltage to implement load braking.
The factory changes with the voltage level.
Setting range: 200.0–2000.0V
In order to prevent customers set the value is too large,
it is recommended setting range:
Voltage
Range
0: Rated running mode
1: The fan keeps on running after power on
0x00–0x21
LED ones: PWM mode selection
0: PWM mode 1, three-phase modulation and
two-modulation
1: PWM mode 2, three-phase modulation
LED tens: low-speed carrier frequency limit mode
0: Low-speed carrier frequency limit mode 1, the carrier
frequency will limit to 2k if it exceeds 2k at low speed
1: Low-speed carrier frequency limit mode 2, the carrier
frequency will limit to 4k if it exceeds 4k at low speed
2: No limit
LED ones
0: Invalid
1: Valid
LED tens (for factory commissioning)
0: Light overcommission; in zone 1
1: Heavy overcommission; in zone 2
0x0000–0x1223
LED ones: frequency enable selection
0: Both ∧/∨ keys and analog potentiometer
adjustments are valid
1: Only ∧/∨ keys adjustment is valid
2: Only analog potentiometer adjustments is valid
220V 460V
375–400V 715–780V
-65-
Function Parameters
Default
Modify
value
○
0
220V
voltage:
380.0V
○
460V
voltage:
740.0V
○
0
◎
0x01
◎
0x00
○
0x0000
