TECHTOP TD20 Series Product Manual page 38

TD20 Series VFD
Function
Name
code
Stator resistor
of
P02.06
asynchronous
motor
Rotor resistor
of
P02.07
asynchronous
motor
Leakage
inductance of
P02.08
asynchronous
motor
Mutual
inductance of
P02.09
asynchronous
motor
Non-load
current of
P02.10
asynchronous
motor
Magnetic
saturation
P02.11 coefficient 1
for the iron
core of AM1
Magnetic
saturation
P02.12 coefficient 2
for the iron
core of AM1
Magnetic
saturation
P02.13 coefficient 3
for the iron
core of AM1
Magnetic
P02.14 saturation
coefficient 4
Detailed instruction of parameters
0.001–65.535Ω
0.001–65.535Ω
0.1–6553.5mH
0.1–6553.5mH
0.1–6553.5A
0.0–100.0%
0.0–100.0%
0.0–100.0%
0.0–100.0%
-36-
Function Parameters
Default
Modify
value
Depend
○
on
model
Depend
○
on
model
Depend
○
on
model
Depend
○
on
model
Depend
○
on
model
◎
80.0%
◎
68.0%
◎
57.0%
◎
40.0%
