TD20 Series VFD
Appendix B Dimension Drawings
Appendix B Dimension Drawings
Dimension drawings of the TD20 are shown below. The dimensions are given in millimeters and inches.
B.1 External keypad (optional) structure
Outline dimensions of the keypad
42.0
5.2
17.1
19.0
48.1 19.0
62.0
2-Ø4.5
16.0
8.0
26.0
Hole dimensions for installing the keypad without a bracket
-117-
