TECHTOP TD20 Series Product Manual page 58

TD20 Series VFD
Function
Name
code
Displayed
parameters 2
P07.06
of running
state
The parameter
P07.07 selection of
the stop state
Frequency
P07.08 display
coefficient
Speed display
P07.09
coefficient
Linear speed
P07.10 displayed
coefficient
Detailed instruction of parameters
BIT13: pulse counter value
BIT14: reserved
BIT15: PLC and the current step of multi-step speed
0x0000–0xFFFF
BIT0: analog AI1 value (V on)
BIT1: analog AI2 value (V on)
BIT2: analog AI3 value (V on)
BIT3: high speed pulse HDI frequency
BIT4: motor overload percentage (% on)
BIT5: the VFD overload percentage (% on)
BIT6: ramp frequency given value (Hz on)
BIT7: linear speed
BIT8: AC inlet current (A on)
BIT9–15: reserved
0x0000–0xFFFF
BIT0: set frequency (Hz on, frequency flickering slowly)
BIT1: bus voltage (V on)
BIT2: input terminals state
BIT3: output terminals state
BIT4: PID reference (% flickering)
BIT5: PID feedback value (% flickering)
BIT6: torque reference (% flickering)
BIT7: analog AI1 value (V on)
BIT8: analog AI2 value (V on)
BIT9: analog AI3 value (V on)
BIT10: high speed pulse HDI frequency
BIT11: PLC and the current step of multi-step speed
BIT12: pulse counters
BIT13–BIT15: reserved
0.01–10.00
Displayed frequency=running frequency x P07.08
0.1–999.9%
Mechanical rotation speed =120 x displayed running
frequency×P07.09/motor pole pairs
0.1–999.9%
Linear speed= Mechanical rotation speed x P07.10
-56-
Function Parameters
Default
Modify
value
0x0000
○
0x00FF
○
1.00
○
100.0%
○
1.0%
