TECHTOP TD20 Series Product Manual page 46

TD20 Series VFD
Function
Name
code
Keypad
P04.28
setting voltage
Voltage
P04.29 increasing
time
Voltage
P04.30 decreasing
time
Output
P04.31 maximum
voltage
Output
P04.32 minimum
voltage
Weakening
coefficient in
P04.33
constant
power zone
Detailed instruction of parameters
6: PID setting voltage;
7: MODBUS communication setting voltage;
8–10: Reversed
Note: 100% corresponds to the rated voltage of the
motor.
The function code is the voltage digital set value when
the voltage setting channel is selected as "keypad
selection".
Setting range: 0.0%–100.0%
Voltage increasing time is the time when the VFD
accelerates from the output minimum voltage to the
output maximum voltage.
Voltage decreasing time is the time when the VFD
decelerates from the output maximum voltage to the
output minimum voltage.
Setting range: 0.0–3600.0s
Set the upper and low limit of the output voltage.
Setting range of P04.31: P04.32–100.0%
(the rated voltage of the motor)
Setting range of P04.32: 0.0%– P04.31
(the rated voltage of the motor)
Vmax
Vset
Vmin
t1
Adjust the output voltage of the VFD in SVPWM mode
when weakening.
Note: Invalid in the constant torque mode.
Output Voltage
V
out
V
b
Setting range of P04.33: 1.00–1.30
t1=P04.29
t2=P04.30
t2
Time
(P04.33-1.00) x V
Output frequency
f 2f
b b
-44-
Function Parameters
Default
value
100.0%
5.0s
5.0s
100.0%
0.0%
b
1.00
Modify
○
○
○
◎
◎
○
