TECHTOP TD20 Series Product Manual page 53

TD20 Series VFD
Function
Name
code
HDI low
frequency
setting
Upper limit
P05.52 frequency of
HDI
Correspondin
g setting of
P05.53 upper limit
frequency of
HDI
HDI frequency
P05.54
input filter time
P06 Group Output terminals
Y1 output
P06.01
selection
Relay RO1
P06.03 output
selection
Relay RO2
P06.04 output
selection
Detailed instruction of parameters
P05.50–50.000kHz
-100.0%–100.0%
0.000s–10.000s
0: Invalid
1: In operation
2: Forward rotation operation
3: Reverse rotation operation
4: Jogging operation
5: The VFD fault
6: Frequency degree test FDT1
7: Frequency degree test FDT2
8: Frequency arrival
9: Zero speed running
10: Upper limit frequency arrival
11: Lower limit frequency arrival
12: Ready for operation
13: Pre-magnetizing
14: Overload pre-alarm
15: Underload pre-alarm
16: Completion of simple PLC stage
17: Completion of simple PLC cycle
18: Setting count value arrival
19: Defined count value arrival
20: External fault valid
21: Reserved
22: Running time arrival
23: MODBUS communication virtual terminals output
24–25: Reserved
-51-
Function Parameters
Default
Modify
value
50.000
○
kHz
○
100.0%
○
0.100s
0
○
1
○
5
