TECHTOP TD20 Series Product Manual page 37

TD20 Series VFD
Function
Name
code
Start delay
P01.23
time
Delay of the
P01.24 stopping
speed
P01.25 0Hz output
P02 Group Motor 1
Rated power
of
P02.01
asynchronous
motor
Rated
frequency of
P02.02
asynchronous
motor
Rated speed
of
P02.03
asynchronous
motor
Rated voltage
of
P02.04
asynchronous
motor
Rated current
of
P02.05
asynchronous
motor
Detailed instruction of parameters
The function determines the brake release after the
running command is given, and the VFD is in a stand-by
state and wait for the delay time set by P01.23
Setting range: 0.0–60.0s
Setting range: 0.0–100.0s
Select the 0Hz output of the VFD.
0: Output without voltage
1: Output with voltage
2: Output at the DC braking current
0.1–3000.0kW
Note: The value entered in this parameter must be in
kW.
Power (kW)
0.4
0.75
1.5
2.2
0.01Hz–P00.03
1–36000rpm
0–1200V
0.8–6000.0A
Horsepower (HP)
0.5
1
2
3
-35-
Function Parameters
Default
Modify
value
○
0.0s
○
0.0s
○
0
Depend
◎
on
model
◎
60.00Hz
Depend
◎
on
model
Depend
◎
on
model
Depend
◎
on
model
